System And Components
347-6862 GEAR GP-INPUT TRANSFERS/N M5L1-UP
Group No: 347-6862
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6H3568 | 1 CUP-BEARING | 2 | |
| 6V0852 | 2 CAP-DUST | 1 | |
| 1108403 | 3 CAGE-BEARING | 1 | |
| 1116261 | 4 MANIFOLD-LUBRICATION OIL | 1 | |
| 1128633 | 5 SHIM PACK (INCLUDES 11-SHIMS) | 2 | |
| 1129645 | 6 TUBE AS | 1 | |
| 1129646 | 7 TUBE AS | 1 | |
| 1228863 | 8 SENSOR GP-SPEED (MAGNETIC, LOW OUTPUT)(TRANSMISSION INPUT) | 1 | |
| 1402802 | 9 CAGE AS | 1 | |
| 8T5089 | PIN-SPRING | 1 | |
| 1629969 | 10 YOKE AS | 1 | |
| 2H3934 | SEAL-O-RING | 1 | |
| 8K2692 | RING-RETAINING | 1 | |
| 1546534 | PLUG | 1 | |
| 1917805 | 11 ELBOW AS | 2 | |
| 0307947 | ADAPTER-ELBOW | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 2837688 | 12 CASE AS-TRANSMISSION | 1 | |
| 2D6642 | BALL | 2 | |
| 9M4007 | DOWEL | 1 | |
| 3474439 | 13 TEE AS | 1 | |
| 6M6853 | TEE-O-RING | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1097389 | 14 GEAR-INPUT (56-TEETH) | 1 | |
| 1097390 | 15 GEAR-OUTPUT (51-TEETH) | 1 | |
| 1293172 | 16 STUD-MOUNTING (3/8-16X1.564-IN) | 6 | |
| 1645567 | 17 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1A2029 | 18 BOLT (3/8-16X1.125-IN) | 16 | |
| 1B7709 | 19 BOLT (5/8-11X8-IN) | 12 | |
| 1P4693 | 20 CUP-BEARING | 2 | |
| 1P4694 | 21 CONE-BEARING | 2 | |
| 2160273 | 22 SEAL-LIP TYPE | 1 | |
| 3K0360 | 23 SEAL-O-RING | 1 | |
| 4S5898 | 24 SEAL-O-RING | 1 | |
| 5M2894 | 25 WASHER-HARD (10.2X18.5X2.5-MM THK) | 8 | |
| 5P2861 | 26 SEAL-O-RING | 1 | |
| 5P8247 | 27 WASHER-HARD (17X32X3.5-MM THK) | 12 | |
| 6I8849 | 28 CONE-BEARING (TAPERED ROLLER) | 2 | |
| 6V1179 | 29 SEAL-O-RING | 1 | |
| 6V3348 | 30 SEAL-O-RING | 1 | |
| 8C3828 | 31 SEAL-O-RING | 1 | |
| 8M9024 | 32 WASHER-HARD (10.2X22.5X5-MM THK) | 6 |
