System And Components
207-9754 VALVE & LINES GP-COUPLERS/N 4NZ3400-UP; 5FZ6700-UP
Group No: 207-9754
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1242456 | 1 FILM-INSTRUCTION (NO STEP) | 1 | |
| 1662033 | 2 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X2444 | TEE-SWIVEL | 1 | |
| 2079737 | 3 BRACKET AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 2 | |
| 2079756 | 4 HOSE AS | 4 | |
| 2090640 | 5 VALVE & MTG GP-SOLENOID (QUICK COUPLER) | 1 | |
| 2126690 | 6 GUARD | 1 | |
| 2153191 | 7 REDUCER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8937 | REDUCER | 1 | |
| 2194335 | 8 HOSE AS | 2 | |
| 2208086 | 9 TUBE AS | 1 | |
| 2208087 | 10 TUBE AS | 1 | |
| 2208088 | 11 HOSE AS | 2 | |
| 2208089 | 12 HOSE AS | 1 | |
| 2208090 | 13 TUBE AS | 1 | |
| 1488325 | 14 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488336 | 15 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488378 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1504031 | 17 TEE AS | 1 | |
| 6V9845 | TEE-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 3 | |
| 1504034 | 18 TEE AS | 2 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 8T0379 | TEE-BULKHEAD | 1 | |
| 2V3216 | 19 CLIP (LOOP) | 4 | |
| 5C7261 | 20 NUT (M8X1.25-THD) | 1 | |
| 5K8451 | 21 CLIP (LOOP) | 2 | |
| 6V8397 | 22 SEAL-O-RING | 4 | |
| 6V8555 | 23 NUT-FACE SEAL (1-14-THD) | 1 | |
| 6V9168 | 24 NUT (11/16-16-THD) | 2 | |
| 7G2950 | 25 CLIP (SLOT) | 1 | |
| 7G2951 | 26 CLIP (TAB) | 1 | |
| 7H7055 | 27 CLIP | 2 | |
| 7X7729 | 28 WASHER (11X25X3-MM THK) | 4 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 30 NUT (M10X1.5-THD) | 1 | |
| 8T4189 | 31 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4191 | 32 BOLT (M10X1.5X16-MM) | 2 | |
| 8T4195 | 33 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4201 | 34 BOLT-LOCKING (M10X1.5X20-MM) | 2 | |
| 8T4224 | 35 WASHER-HARD (8.8X16X2-MM THK) | 6 | |
| 8T4908 | 36 BOLT (M8X1.25X25-MM) | 1 | |
| 8T6870 | 37 BOLT (M8X1.25X70-MM) | 2 | |
| 9M8406 | 38 CLIP (LOOP) | 2 | |
| 9R1004 | 39 CLIP (TAB) | 1 | |
| 9R1005 | 40 CLIP (SLOT) | 1 |
