System And Components
142-8799 CYLINDER & MTG GP-LIFT ARMS/N CML1-UP
Group No: 142-8799
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1428789 | 1 SUPPORT AS | 1 | |
| 1428790 | 2 PIN AS | 4 | |
| 1428791 | 3 PIN AS | 2 | |
| 1428792 | 4 PIN | 1 | |
| 1428793 | 5 PIN | 2 | |
| 1428794 | 6 PIN | 1 | |
| 1428808 | 7 SPACER (32.5X50.5X28-MM THK) | 2 | |
| 1428832 | 8 PIN AS | 1 | |
| 1428880 | 9 LEVER | 1 | |
| 1428881 | 10 BRACKET | 1 | |
| 1428960 | 11 CYLINDER GP-LIFT (RH) | 1 | |
| 1428961 | 12 CYLINDER GP-LIFT (LH) | 1 | |
| 1779568 | 13 CYLINDER GP-TILT (RH) | 1 | |
| 1779569 | 14 CYLINDER GP-TILT (LH) | 1 | |
| 1919588 | 15 PIN AS | 2 | |
| 3B8489 | 16 FITTING-GREASE (1/8-27 PTF) | 10 | |
| 3S8536 | 17 SPACER (0.406X0.656X0.38-IN THK) | 1 | |
| 4M5285 | 18 RING-RETAINING | 4 | |
| 5H9743 | 19 GROMMET | 1 | |
| 6V9189 | 20 LOCKNUT (M8X1.25-THD) | 2 | |
| 7X7729 | 21 WASHER (11X25X3-MM THK) | 8 | |
| 8T3647 | 22 BOLT (M8X1.25X80-MM) | 2 | |
| 8T4121 | 23 WASHER-HARD (11X21X2.5-MM THK) | 1 | |
| 8T4136 | 24 BOLT (M10X1.5X25-MM) | 1 | |
| 8T4189 | 25 BOLT (M8X1.25X20-MM) | 1 | |
| 8T4191 | 26 BOLT (M10X1.5X16-MM) | 8 | |
| 8T4224 | 27 WASHER-HARD (8.8X16X2-MM THK) | 1 |
