System And Components
115-8336 LINES GP-LUBRICATIONS/N BYG1-UP; AGP1-UP
Group No: 115-8336
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8I0972 | 1 VALVE | 2 | |
| 7X3178 | 2 BOLT (1/4-20X1.625-IN) | 4 | |
| 8T4205 | 3 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 3D6209 | 4 GROMMET | 4 | |
| 1212488 | 5 TUBE AS | 2 | |
| 1212489 | 6 TUBE AS | 1 | |
| 1212490 | 7 TUBE AS | 1 | |
| 1212492 | 8 TUBE AS | 1 | |
| 2D1683 | 9 FITTING (1/8-27 PTF) | 2 | |
| 1488320 | 10 CONNECTOR AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6865 | CONNECTOR | 1 | |
| 3B7896 | 11 ELBOW-STREET | 2 | |
| 1837258 | 12 ELBOW AS | 4 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X5331 | ELBOW | 1 | |
| 1488337 | 13 CONNECTOR AS | 6 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 8C6866 | CONNECTOR | 1 | |
| 3B8485 | 14 ELBOW | 2 | |
| 4M5317 | 15 BUSHING-REDUCER | 2 | |
| 1212491 | 16 TUBE AS | 1 | |
| 1488389 | 17 ELBOW AS | 14 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 7X0492 | ELBOW | 1 | |
| 3B6487 | 18 COUPLING (PIPE) | 2 | |
| 6V1813 | 19 FITTING | 2 | |
| 7R6037 | 20 CLAMP | 18 | |
| 7X2501 | 21 BOLT (1/4-20X1.25-IN) | 18 | |
| 7R7950 | 22 PLATE | 9 | |
| 2T2243 | 23 HOSE AS | 1 | |
| 7T4458 | 24 HOSE AS | 2 | |
| 8W9339 | 25 HOSE AS | 1 | |
| 1340710 | 26 HOSE AS | 1 | |
| 1082201 | 27 TUBE AS | 1 | |
| 1212494 | 28 TUBE AS | 1 | |
| 1212493 | 29 TUBE AS | 1 |
