System And Components
278-8487 CONTROL AR-AIR SYSTEM -MAINS/N SSP118-138
Group No: 278-8487
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2D7325 | 1 TEE-PIPE | 1 | |
| 2F1336 | 2 FITTING-HEAD | 1 | |
| 2H3940 | 3 ELBOW | 1 | |
| 3B8822 | 4 ELBOW | 1 | |
| 3D7587 | 5 ELBOW | 5 | |
| 5D6998 | 6 HORN GP-AIR | 1 | |
| 5D7132 | 7 CLAMP | 2 | |
| 5D7133 | 8 BRACKET | 1 | |
| 5F5434 | 9 VALVE AS-VENT (AIR START) | 1 | |
| 5F5434 | 9A VALVE AS-VENT (AUTOLUBE) | 1 | |
| 6B9664 | 10 VALVE-AIR RELIEF (AIR TANK) | 1 | |
| 5240073 | VALVE-AIR RELIEF | 1 | |
| 7D6936 | 11 VALVE AS-CHECK (AIR TANK) | 1 | |
| 9M7357 | 12 COUPLING AS | 1 | |
| 9X3495 | 13 CLIP AS | 1 | |
| 7C2642 | CLIP | 1 | |
| 8C3334 | RIVET-TUBULAR | 2 | |
| 1415746 | 14 SENSOR GP-PRESSURE (AIR SYSTEM) | 1 | |
| 1837258 | 15 ELBOW AS | 1 | |
| 7X5331 | ELBOW | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 1850008 | 16 VALVE GP-SOLENOID (24-VOLT)(AIR HORN) | 1 | |
| 1996290 | 17 ELBOW AS | 1 | |
| 2T2305 | ELBOW | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2219576 | 18 VALVE GP-SOLENOID (24-VOLT)(AIR STARTING) | 1 | |
| 2219576 | 18A VALVE GP-SOLENOID (24-VOLT)(AUTOLUBE ACTUATION) | 1 | |
| 2219578 | KIT-VALVE | 1 | |
| 2640063 | 19 PLATE | 1 | |
| 2935846 | 20 BRACKET | 1 | |
| 2958715 | 21 PLATE AS | 1 | |
| 8T3597 | NUT-WELD (M12X1.75-THD) | 1 | |
| 2958716 | 22 HOSE AS | 1 | |
| 2968252 | 23 HOSE AS | 1 | |
| 2968253 | 24 HOSE AS | 1 | |
| 2968254 | 25 HOSE AS | 1 | |
| 2968255 | 26 HOSE AS | 1 | |
| 2968256 | 27 HOSE AS | 1 | |
| 2968258 | 28 HOSE AS | 1 | |
| 2999373 | 29 HOSE AS | 1 | |
| 3001345 | 30 HOSE AS | 1 | |
| 3001358 | 31 PLATE AS | 1 | |
| 3001359 | PLATE | 1 | |
| 8T3490 | NUT-WELD (M10X1.5-THD) | 1 | |
| 3028496 | 32 CONNECTOR | 1 | |
| 3057509 | 33 HOSE AS | 1 | |
| 3063045 | 34 PUMP GP-LUBRICATION | 1 | |
| 3399752 | 35 PLATE | 1 | |
| 3412120 | 36 AIR DRYER GP | 1 | |
| 3469262 | 37 TUBE AS | 1 | |
| 3469263 | 38 HOSE AS | 1 | |
| 3470574 | 39 HOSE AS | 1 | |
| 3B7738 | 40 FITTING | 1 | |
| 0115224 | 41 BUSHING-REDUCER | 1 | |
| 0308370 | 42 ADAPTER-PIPE | 1 | |
| 1095605 | 43 ADAPTER-PIPE | 2 | |
| 1276241 | 44 SPACER (12X16X42-MM THK) | 1 | |
| 1495452 | 45 UNION AS (STRAIGHT) | 1 | |
| 6V8994 | UNION (STRAIGHT) | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 1600980 | 46 BLOCK | 1 | |
| 1694279 | 47 CONNECTOR AS | 2 | |
| 8C6872 | CONNECTOR | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1745907 | 48 CLIP | 9 | |
| 1S0994 | 49 CLIP (LOOP) | 2 | |
| 2458842 | 50 CLIP (LOOP) | 1 | |
| 2H9523 | 51 GROMMET | 1 | |
| 2H9524 | 52 GROMMET | 1 | |
| 2Y3812 | 53 CLIP | 1 | |
| 2Y4062 | 54 ADAPTER | 1 | |
| 3B6553 | 55 ELBOW | 1 | |
| 3E7448 | 56 CONNECTOR | 1 | |
| 3J7354 | 57 SEAL-O-RING | 1 | |
| 4D0124 | 58 ELBOW | 2 | |
| 4D2560 | 59 CONNECTOR-PIPE | 2 | |
| 4H6147 | 60 CONNECTOR | 2 | |
| 4K8302 | 61 CLIP (LOOP) | 2 | |
| 4N3411 | 62 VALVE GP-RELAY (AIR STARTING MOTOR) | 1 | |
| 7C5105 | KIT-VALVE SEAL (AIR STARTING) | 1 | |
| 5C2890 | 63 NUT (M6X1-THD) | 6 | |
| 5H4778 | 64 ELBOW | 3 | |
| 5M6213 | 65 PLUG-PIPE (1/4-18-THD) | 1 | |
| 5P1076 | 66 WASHER-HARD (13.5X30X4-MM THK) | 6 | |
| 5P7854 | 67 CLIP (LOOP) | 1 | |
| 5P8753 | 68 TEE | 1 | |
| 5P8998 | 69 FITTING (1/4-18-THD) | 1 | |
| 5P9297 | 70 CLIP (LOOP) | 1 | |
| 5S7349 | 71 BOLT (1/4-20X0.5-IN) | 2 | |
| 6D4244 | 72 CLIP (LOOP) | 4 | |
| 6K1019 | 73 NIPPLE-PIPE | 1 | |
| 6K8178 | 74 CLIP (LOOP) | 2 | |
| 6V8397 | 75 SEAL-O-RING | 1 | |
| 6V9168 | 76 NUT (11/16-16-THD) | 1 | |
| 7G8839 | 77 SPACER (13.5X57X6-MM THK) | 2 | |
| 7T8331 | 78 MOUNT AS | 2 | |
| 7X2533 | 79 BOLT (M6X1X35-MM) | 2 | |
| 7X2535 | 80 BOLT (M6X1X60-MM) | 2 | |
| 7X2537 | 81 BOLT (M8X1.25X35-MM) | 1 | |
| 8B2664 | 82 BUSHING-REDUCER | 1 | |
| 8B9913 | 83 ELBOW-REDUCING | 1 | |
| 8D4755 | 84 REGULATOR | 1 | |
| 8T4121 | 85 WASHER-HARD (11X21X2.5-MM THK) | 33 | |
| 8T4133 | 86 NUT (M10X1.5-THD) | 3 | |
| 8T4136 | 87 BOLT (M10X1.5X25-MM) | 18 | |
| 8T4137 | 88 BOLT (M10X1.5X20-MM) | 11 | |
| 8T4138 | 89 BOLT (M6X1X20-MM) | 2 | |
| 8T4183 | 90 BOLT (M12X1.75X40-MM) | 3 | |
| 8T4184 | 91 BOLT (M12X1.75X45-MM) | 1 | |
| 8T4186 | 92 BOLT (M10X1.5X40-MM) | 7 | |
| 8T4192 | 93 BOLT (M12X1.75X25-MM) | 1 | |
| 8T4195 | 94 BOLT (M10X1.5X30-MM) | 1 | |
| 8T4205 | 95 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 8T4223 | 96 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4910 | 97 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4956 | 98 BOLT (M12X1.75X35-MM) | 6 | |
| 8T6466 | 99 BOLT (M10X1.5X60-MM) | 1 | |
| 8T9364 | 100 BOLT (1/4-20X0.625-IN) | 2 | |
| 9C5344 | 101 SPACER (10.5X20X18-MM THK) | 7 | |
| 9M8406 | 102 CLIP (LOOP) | 23 | |
| 9X6165 | 103 WASHER (6.5X22X2.5-MM THK) | 2 | |
| 9X8256 | 104 WASHER (6.6X12X2-MM THK) | 6 |
