System And Components
367-9478 CYLINDER GP-TILTS/N AK71-UP; 2B31-UP; SGZ1-UP
Group No: 367-9478
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2J0564 | 1 LOCKNUT (2-12-THD) | 1 | |
| 5J4991 | 2 SEAL AS | 1 | |
| 8E5703 | 3 SHIM (0.8-MM THK) | 24 | |
| 8J2880 | 4 CAP AS-BEARING | 1 | |
| 2339135 | 5 CYLINDER AS | 1 | |
| 2J8489 | 5A BEARING | 1 | |
| 2339138 | 6 HEAD-CYLINDER | 1 | |
| 3124247 | 7 SEAL-WIPER | 1 | |
| 3124248 | 8 SEAL AS-BUFFER | 1 | |
| 3644416 | 9 ROD AS | 1 | |
| 3J6572 | SHIM (0.5-MM THK) | 14 | |
| 3679479 | 10 PISTON | 1 | |
| 3124245 | 11 SEAL-U-CUP | 1 | |
| 3J9703 | 12 RING-WEAR | 1 | |
| 6V7742 | 13 NUT-FULL (M20X2.5-THD) | 4 | |
| 6V8133 | 14 BOLT (M24X3X80-MM) | 4 | |
| 6V8237 | 15 WASHER (26X44X4-MM THK) | 4 | |
| 6V9167 | 16 BOLT (M20X2.5X140-MM) | 4 | |
| 7J8955 | 17 RING-BACKUP | 1 | |
| 7J8956 | 18 SEAL-O-RING | 1 | |
| 8T8379 | 19 SEAL-HEAD | 1 | |
| 9T0094 | 20 RING-WEAR | 1 | |
| 2440980 | KIT-SEAL (TILT CYLINDER) | 1 |
