7C-0875 DRIVE GP-FANAN ATTACHMENT

Group No: 7C-0875
Part NumberPart NameQty
0S16171 BOLT (5/16-18X0.75-IN)4
9M1974WASHER-HARD (8.8X16X2-MM THK)4
7C08642 PULLEY-IDLER1
7C08623 ARM AS-TIGHTENER1
0S15944 BOLT (3/8-16X1-IN)1
5M2894WASHER-HARD (10.2X18.5X2.5-MM THK)1
8S62125 BOLT (1/2-13X13-IN)2
4M96416 BOLT (1/2-13X12.75-IN)2
4S58827 BOLT (1/2-13X7.25-IN)3
5P82458 WASHER-HARD (13.5X25.5X3-MM THK)7
7C08599 BRACKET AS-FAN1
7W6488SHAFT (LARGE)1
1S9209SHAFT-TIGHTENER1
8H9189DOWEL1
1D4612BOLT (3/4-10X4-IN)1
7W7590SLEEVE1
5P8248WASHER-HARD (20X36.5X3.5-MM THK)1
7C086510 SPRING2
5D102611 CLAMP-BAND1
5P7102HOSE (LG)
0S159412 BOLT (3/8-16X1-IN)2
8B8679SPACER (0.406X0.75X0.44-IN THK)1
9L9132WASHER-HARD (10.2X25.5X2.5-MM THK)2
7C085813 BAR1
7C085414 PLATE1
8T783415 BOLT (1/2-13X7.5-IN)1
5P824516 WASHER-HARD (13.5X25.5X3-MM THK)4
1J403417 SEAL-LIP TYPE1
3B848918 ADAPTER2
4B455019 FITTING-PRESSURE RELIEF (1/8-27 PTF)2
9Y264720 HUB-FAN PULLEY1
3B191521 BOLT (3/8-16X1.375-IN)8
6B322422 CUP-BEARING (TAPERED ROLLER)2
4B725523 CONE-BEARING2
5F314424 SEAL-O-RING1
065789225 WASHER (2.4X3.75X0.187-IN THK)1
2H377826 LOCKNUT1
7W346427 ADAPTER-FAN1
065789328 LOCKWASHER-BEARING1
0S157129 BOLT (3/8-16X1.75-IN)12
6F528130 BOLT (1/2-13X10-IN)2
1K4649SPACER (0.516X1X1-IN THK)1
2M274231 PLATE-RETAINER1
2N837432 GASKET1
7W846133 COVER1
0L207034 BOLT (3/8-16X2.25-IN)2
7W846035 WASHER-RETAINING1
8N941936 SPACER (18.25-MM THK)1
8H978937 BALL BEARING2
8N941038 SPACER (16-MM THK)1
5S210639 SEAL-LIP TYPE1
5M205740 SEAL-O-RING1
3B461741 PIN-COTTER2
0S0175PIN-CLEVIS2
