System And Components
9N-6669 BELT TENSIONER GPS/N 63W4200-UP
Group No: 9N-6669
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9N6670 | 1 ARM AS | 1 | |
| 4S5367 | 2 BUSHING AS (MOUNT) | 1 | |
| 4N0955 | 3 DOWEL | 1 | |
| 8N4550 | 4 SHAFT-PULLEY | 1 | |
| 8T4896 | 5 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 6N3641 | 6 PULLEY-TIGHTENER | 1 | |
| 5M9735 | 7 SEAL-LIP TYPE | 1 | |
| 6B1124 | 8 BALL BEARING | 2 | |
| 1S8687 | 9 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 8B2327 | 10 RING-RETAINING | 1 | |
| 2S6160 | 11 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 5M3062 | 12 BOLT (3/8-16X0.75-IN) | 1 | |
| 2S6150 | 13 COVER-PULLEY | 1 | |
| 2S6151 | 14 GASKET | 1 | |
| 4M6425 | 15 BOLT (5/16-18X1-IN) | 4 | |
| 7W1399 | 16 RETAINER-SPRING | 1 | |
| 6V8188 | 17 NUT (1/2-13-THD) | 1 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 1 | |
| 7N5959 | 19 SPRING | 1 | |
| 0S0175 | 20 PIN-CLEVIS | 2 | |
| 3B4617 | 21 PIN-COTTER | 2 | |
| 3B8489 | 22 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 2M2742 | 23 PLATE-RETAINER | 1 | |
| 5S7379 | 24 BOLT (3/8-16X0.875-IN) | 1 |
