System And Components
8Y-5986 SEAT GP -CLOTHS/N 5DR1-99999
Group No: 8Y-5986
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8Y5947 | 1 FASTENER | 4 | |
| 8Y5992 | 2 PAN GP-SEAT | 1 | |
| 1130899 | 3 SCREW-FLAT HEAD (6-20X0.5-IN) | 10 | |
| 9L7469 | 4 LOCK PIN | 2 | |
| 5P7076 | 5 BOLT-12 POINT HEAD (7/16-20X1.25IN) | 2 | |
| 7B7525 | BOLT-SOCKET HEAD (7/16-14X1.25-IN) | 2 | |
| 2K4973 | 6 LOCKNUT (3/8-16-THD) | 6 | |
| 8Y5929 | 7 PLATE AS-SLIDE | 1 | |
| 4K9097 | NUT-WELD (5/16-18-THD) | 6 | |
| 8Y5930 | 8 BAR AS | 1 | |
| 8Y5931 | 9 BAR AS | 1 | |
| 8S7803 | 10 RING-RETAINING | 2 | |
| 8Y5932 | 11 LATCH AS | 1 | |
| 8Y5936 | 12 SPRING | 1 | |
| 0950878 | 13 PIN-SPRING | 1 | |
| 8Y5981 | 14 BUSHING-BACKREST | 2 | |
| 8Y5928 | 15 SPRING | 2 | |
| 2B2695 | 16 BOLT (5/16-18X0.875-IN) | 4 | |
| 8Y5937 | 17 BRACKET AS (RH) | 1 | |
| 8Y5938 | 18 BRACKET AS (LH) | 1 | |
| 7U4898 | 19 SCREW (3/8-16X0.75-IN) | 6 | |
| 1C0569 | 20 BOLT (5/16-18X0.5-IN) | 2 | |
| 8Y5979 | 21 PIN | 1 | |
| 6V2456 | 22 RING-RETAINING | 2 | |
| 8Y6834 | 23 SPRING (LH) | 1 | |
| 8Y6833 | 24 SPRING (RH) | 1 | |
| 1088421 | 25 PAN GP-BACKREST (LUMBAR) | 1 | |
| 8Y5903 | 26 CAM | 2 | |
| 8Y6006 | 27 LID AS | 1 | |
| 8Y6010 | 28 LANYARD | 1 | |
| 5P7958 | SLEEVE-CABLE SPLICE | ||
| 4S8287 | 29 RIVET-POP | 8 | |
| 8Y5972 | 30 LATCH | 1 | |
| 9M5733 | 31 RIVET-POP | 2 | |
| 3E4336 | 32 STUD-BALL | 1 | |
| 3E4335 | 33 CLIP | 1 | |
| 3E6575 | 34 SEAL | ||
| 8F1462 | 35 WASHER-PLATED | 1 | |
| 2F7306 | 36 SCREW-MACHINE (6-32X0.25-IN) | 1 | |
| 3E4362 | 37 PIN-SPRING | 2 | |
| 1088423 | 38 SHAFT AS-LUMBAR | 1 | |
| 1088424 | 39 PAN-LUMBAR | 1 | |
| 0618803 | 40 SHIM (1.52-MM THK) | 4 | |
| 1088426 | 41 CUSHION AS-BACK (CLOTH) | 1 | |
| 8Y6051 | 42 SPACER (11.19X14.21X14.24-MM THK) | 2 | |
| 8Y6933 | KIT-TILT PAN | 1 | |
| 1124577 | KIT-SEAT KNOB | 1 | |
| 8Y5891 | KIT-SEAT CUSHION (BOTTOM) | 1 | |
| 1494745 | KIT-SLIDER BLOCK (SUSPENSION SEAT) | 1 |
