System And Components
114-5540 BELT TENSIONER GPS/N 8BL1053-UP
Group No: 114-5540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1144246 | 1 ARM AS-TIGHTENER | 1 | |
| 2S6196 | SHAFT-PULLEY | 1 | |
| 4S5367 | BUSHING AS (MOUNT) | 1 | |
| 7N5352 | DOWEL | 1 | |
| 1360866 | 2 STUD | 1 | |
| 6S6308 | 3 PIN | 1 | |
| 1144294 | 4 PULLEY-TIGHTENER (4-GROOVE) | 1 | |
| 1617128 | 6 SPRING AS | 1 | |
| 7I1334 | HOSE | 1 | |
| 2K4973 | 7 LOCKNUT (3/8-16-THD) | 1 | |
| 2M2742 | 8 PLATE-RETAINER | 1 | |
| 4L6454 | 9 BOLT (3/8-16X1-IN) | 1 | |
| 4M6425 | 10 BOLT (5/16-18X1-IN) | 4 | |
| 1S8687 | 11 SPACER (25.5X33.4X31.75-MM THK) | 1 | |
| 5M9735 | 12 SEAL-LIP TYPE | 1 | |
| 8B2327 | 13 RING-RETAINING | 1 | |
| 0S0509 | 14 BOLT (3/8-16X0.75-IN) | 1 | |
| 6B1124 | 15 BALL BEARING | 2 | |
| 2S6151 | 16 GASKET | 1 | |
| 2S6150 | 17 COVER-PULLEY | 1 | |
| 2S6160 | 18 WASHER-HARD (10.2X32X5-MM THK) | 1 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 3B4617 | 20 PIN-COTTER | 1 | |
| 3B8485 | 21 ELBOW | 1 |
