System And Components
250-3217 GEAR & CASE GP-TRANSFERS/N MRB602-UP
Group No: 250-3217
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1349817 | 1 CASE AS-TRANSFER | 1 | |
| 0S1594 | BOLT (3/8-16X1-IN) | 1 | |
| 4D6473 | DOWEL | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8P8837 | TUBE AS | 1 | |
| 8M8659 | DOWEL | 2 | |
| 6Y6328 | 2 SHIM PACK (INCLUDES 13-SHIMS) | 1 | |
| 0S1587 | 3 BOLT (1/2-13X1.75-IN) | 11 | |
| 5P8245 | 4 WASHER-HARD (13.5X25.5X3-MM THK) | 38 | |
| 1235298 | 5 CAGE-BEARING | 1 | |
| 6Y6329 | 6 SHIM PACK (INCLUDES 13-SHIMS) | 1 | |
| 1232997 | 7 CAGE AS-BEARING | 1 | |
| 3D0490 | STUD-TAPERLOCK (1/2-13X1.97-IN) | 4 | |
| 3F5792 | 8 SEAL-O-RING | 1 | |
| 1P9269 | 9 COVER | 1 | |
| 1F7958 | 10 NUT-FULL (1/2-13-THD) | 4 | |
| 1A1460 | 11 BOLT (1/2-13X2-IN) | 7 | |
| 1730715 | 12 YOKE AS | 1 | |
| 8E4765 | GUARD | 1 | |
| 1730714 | YOKE | 1 | |
| 2379848 | 13 CAGE-BEARING | 1 | |
| 1784641 | 14 CUP-BEARING | 2 | |
| 1784640 | 15 CONE-BEARING | 2 | |
| 5J1086 | 16 SEAL-O-RING | 1 | |
| 1P4078 | 17 SPACER (90.47X107.95X10.08-MM THK) | 1 | |
| 6P4947 | 18 RETAINER | 1 | |
| 2A4639 | 19 BOLT (3/8-16X1.625-IN) | 6 | |
| 5M2894 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 6Y6441 | 21 SHAFT-TRANSFER | 1 | |
| 5M2057 | 22 SEAL-O-RING | 1 | |
| 9J7031 | 23 PLUG-DRAIN | 1 | |
| 2H6490 | 24 BEARING-INNER | 1 | |
| 2H6489 | 25 RACE-BEARING OUTER | 1 | |
| 2K4472 | 26 SEAL-O-RING | 1 | |
| 2379849 | 27 CAGE-BEARING | 1 | |
| 1730714 | 28 YOKE | 1 | |
| 7K1695 | 29 RETAINER | 2 | |
| 1A3103 | 30 BOLT (3/4-16X3.75-IN) | 2 | |
| 2H3933 | 31 SEAL-O-RING | 2 | |
| 0343557 | 32 BOLT-LOCKING (3/8-16X1.125-IN) | 8 | |
| 3T6175 | 33 GEAR (35-TEETH) | 1 | |
| 1232877 | 34 GEAR-TRANSFER (35-TEETH) | 1 | |
| 1240503 | 35 CONE-SPECIAL TAPERED | 2 | |
| 1240504 | 36 CUP-TAPERED | 2 | |
| 7L2181 | 37 SEAL-O-RING | 1 | |
| 1232876 | 38 GEAR-TRANSFER (30-TEETH) | 1 | |
| 1A8651 | 39 BOLT (5/8-11X4.5-IN) | 2 | |
| 5P8247 | 40 WASHER-HARD (17X32X3.5-MM THK) | 20 | |
| 5P2587 | 41 SEAL-O-RING | 1 | |
| 1240501 | 42 CONE | 2 | |
| 1240502 | 43 CUP-TAPERED | 2 | |
| 2160273 | 44 SEAL-LIP TYPE | 2 | |
| 9X8873 | 45 BOLT (1/2-13X2.25-IN) | 8 | |
| 1707309 | 46 SPACER (13.5X25.5X11-MM THK) | 3 | |
| 9X8874 | 47 BOLT (1/2-13X3-IN) | 8 | |
| 1U8846 | 48 SEALANT-GASKET | ||
| 1B4367 | 49 BOLT (5/8-11X3-IN) | 18 | |
| 0S1594 | 50 BOLT (3/8-16X1-IN) | 4 | |
| 8T0722 | 51 BOLT-LOCKING (M10X1.5X30-MM) | 2 | |
| 6P4903 | 52 PLATE AS | 1 | |
| 7B3028 | SCREW-DRIVE (NO 4X 3/16-IN) | 2 | |
| 7S2962 | WASHER-SPRING (52.3X82.5X9.1-MM THK) | 1 | |
| 6V5839 | 53 WASHER (11X21X2.5-MM THK) | 2 | |
| 5F0149 | 54 SEAL-O-RING | 1 | |
| 3685063 | 55 TUBE AS | 1 | |
| 8M7160 | MAGNET | 3 | |
| 4S8598 | 56 SCREEN-SUCTION | 1 | |
| 3P8186 | 57 HOUSING-SCREEN | 1 | |
| 9X8875 | 58 BOLT (1/2-13X3.5-IN) | 3 | |
| 2H2665 | 59 SEAL-O-RING | 1 | |
| 3181178 | 60 SENSOR GP-SPEED (MAGNETIC, HIGH OUTPUT) | 2 | |
| 9X8268 | 61 WASHER (17.5X30X3.5-MM THK) | 2 | |
| 1V6341 | 62 SEAL | 2 | |
| 1S6595 | 63 GASKET-OIL SUPPLY | 1 | |
| 5M3154 | 64 COVER | 1 | |
| 6V6317 | 65 BOLT (M10X1.5X20-MM) | 2 | |
| 8T3298 | 66 SEAL-RECTANGULAR | 1 | |
| 8J8782 | 67 BODY-DRAIN VALVE | 1 | |
| 8J8783 | 68 VALVE-DRAIN | 1 | |
| 7B3039 | 69 SPRING | 1 | |
| 1U2827 | 70 GUIDE-VALVE | 1 |
