System And Components
375-0233 PRECLEANER GP-CAB AIRS/N TJA1100-UP
Group No: 375-0233
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 0673676 | 2 REDUCER | 1 | |
| 2350320 | 3 CAP AS-AIR CLEANER (PRECLEANER) | 1 | |
| 3E7404 | CLAMP-HOSE | 1 | |
| 2709442 | 4 SCREW-TRUSS HEAD (M6X1X20-MM) | 4 | |
| 2896215 | 5 PRECLEANER GP-CAB AIR | 1 | |
| 3857511 | MOTOR AS-BLOWER (24-VOLT, CAB AIR) | 1 | |
| 9W0852 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 2982654 | 6 ELBOW-REDUCER | 1 | |
| 3080852 | 7 BRACKET AS | 1 | |
| 3080857 | 8 FILTER GP-CAB AIR (ADVANCED EFFICIENCY) | 1 | |
| 3161161 | 9 TUBE | 1 | |
| 3223876 | 10 COVER AS | 1 | |
| 3223877 | 11 INSULATION | 1 | |
| 3223878 | 12 BRACKET | 1 | |
| 3223879 | 13 BRACKET AS | 1 | |
| 3223881 | 14 ELBOW | 1 | |
| 3853851 | 15 PLATE AS | 1 | |
| 1178929 | 16 WASHER (6.6X22X2-MM THK) | 4 | |
| 1272170 | 17 SCREW-TRUSS HEAD (M8X1.25X20-MM) | 10 | |
| 3E7404 | 18 CLAMP-HOSE | 3 | |
| 5P0599 | 19 CLAMP-BAND | 1 | |
| 5P1717 | 20 CLAMP-HOSE | 2 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 8T4189 | 22 BOLT (M8X1.25X20-MM) | 4 | |
| 9G1307 | 23 GROMMET | 1 | |
| 5P5927 | 24 SEAL (1.0-M) |
