313-9689 BATTERY & WIRING GPS/N Z4W631-UP

Group No: 313-9689

Part Number	Part Name	Qty
3E8320	1 PLATE-INSTRUCTION (BATTERY)	1
3S2093	2 STRAP-CABLE	29
8V0622	3 CABLE AS-BATTERY	1
8C5917	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1M6119	BOLT (5/16-18X1.375-IN)	2
1M6120	NUT (5/16-18-THD)	2
8T9757	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
9G0003	COVER AS-TERMINAL (BLACK)	1
8L8413	STRAP-CABLE (WHITE)	1
9G0004	COVER AS-TERMINAL (RED)	1
8L8413	STRAP-CABLE (WHITE)	1
1305300	4 CLIP	4
1343344	5 STRAP AS	1
1394724	6 CIRCUIT BREAKER AS (30-AMPERE)	1
6V8378	NUT (10-32-THD)	2
8F1434	LOCKWASHER	2
8T0328	WASHER-HARD (5.5X10X1-MM THK)	2
1535710	8 BATTERY GP (12-VOLT, MAINTENANCE FREE, WET)	2
1536281	9 HOLD-DOWN-BATTERY	1
1712206	10 CIRCUIT BREAKER AS (50-AMPERE)	1
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
2532111	LOCKWASHER	2
1712215	11 CIRCUIT BREAKER AS (150-AMPERE)	1
6V8187	NUT (1/4-28-THD)	2
8T4205	WASHER-HARD (7.2X14.5X2-MM THK)	2
2532111	LOCKWASHER	2
1783620	12 STRAP-DUAL CLAMP	1
1883959	13 BRACKET	1
2130730	14 STRAP AS-GROUND	1
7D1649	15 WASHER-HARD (13.5X32X5-MM THK)	1
2309174	16 CIRCUIT BREAKER AS (15-AMPERE)	1
6V8378	NUT (10-32-THD)	2
8F1434	LOCKWASHER	2
8T0328	WASHER-HARD (5.5X10X1-MM THK)	2
2407192	17 RESISTOR AS (1500-OHM, 1-WATT)	4
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8729	PIN-CONNECTOR (16-GA TO 20-GA)	2
2461670	18 BAR	1
3139744	19 CABLE AS	1
8S3020	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1355009	TUBE-HEAT SHRINK (32-MM DIA)(4-CM)
3489152	COVER AS-TERMINAL (BLACK)	1
3524705	TERMINAL AS-BATTERY (NEGATIVE)	1
1M6120	NUT (5/16-18-THD)	2
3T3349	STUD (5/16-18X0.5-IN, 5/16-18X1.5-IN)	1
3524709	COVER AS-TERMINAL (BLACK)	1
3139745	20 CABLE AS	1
8S3020	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
1355009	TUBE-HEAT SHRINK (32-MM DIA)(7-CM)
2167790	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
3139748	21 CABLE AS	1
1M4986	TERMINAL-RING (0-GA, 1/2-IN SCREW)	1
8N0869	COVER-TERMINAL (RED)	1
1355009	TUBE-HEAT SHRINK (32-MM DIA)(7-CM)
1976800	TERMINAL-RING	1
3139752	22 BRACKET AS	1
3264516	23 TIE-CABLE	3
3268812	24 FILM-IDENTIFICATION (CIRCUIT BREAKER)	1
3268814	25 FILM-IDENTIFICATION (CIRCUIT BREAKER)	1
3282089	26 BAR-BUS	1
3527476	27 CABLE AS	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8737	PLUG-SEAL	1
9X9825	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1090887	SLEEVE (58-CM)
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	2
1355009	TUBE-HEAT SHRINK (32-MM DIA)(21-CM)
3487341	COVER-TERMINAL	1
3658779	28 CABLE AS	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8737	PLUG-SEAL	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	2
1355009	TUBE-HEAT SHRINK (32-MM DIA)(22-CM)
9X9825	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
1090887	SLEEVE (109-CM)
1261768	SOCKET-CONNECTOR (14-GA TO 16-GA)	2
1311506	TERMINAL AS	1
2L8079	TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1552270	KIT-CONNECTING PLUG (2-PIN)	1
2838657	TERMINAL-RING	1
3487341	COVER-TERMINAL	1
3527478	29 CABLE AS	1
1P0810	TAPE-ELECTRICAL	8
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8737	PLUG-SEAL	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	2
1355009	TUBE-HEAT SHRINK (32-MM DIA)(19-CM)
7T9987	COVER AS-TERMINAL (RED)	1
3S6049	TERMINAL AS-BATTERY (POSITIVE)	1
1M6119	BOLT (5/16-18X1.375-IN)	1
1M6120	NUT (5/16-18-THD)	1
1090887	SLEEVE (137-CM)
3682369	TAPE (18-CM)
1311506	TERMINAL AS	1
2L8079	TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1552270	KIT-CONNECTING PLUG (2-PIN)	1
2749183	TERMINAL-RING (00-GA, 1/2-IN SCREW)	1
3658771	30 CABLE AS	1
1355009	TUBE-HEAT SHRINK (32-MM DIA)(20-CM)
3264516	TIE-CABLE	1
1S7252	TERMINAL-CABLE (00-GA, 3/8-IN SCREW)	1
8T8737	PLUG-SEAL	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	3
1311504	TERMINAL AS	1
2L8077	TERMINAL-RING (14-GA TO 16-GA, 1/4-IN SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1552270	KIT-CONNECTING PLUG (2-PIN)	1
2841491	SLEEVE (14-CM)
3304374	SLEEVE (36-CM)
3658810	31 RECEPTACLE AS	1
1028802	KIT-RECEPTACLE (2-PIN)	1
8T8737	PLUG-SEAL	1
9X3401	PIN-CONNECTOR (16-GA TO 18-GA)	1
9X3402	SOCKET-CONNECTOR (16-GA TO 18-GA)	2
1355009	TUBE-HEAT SHRINK (32-MM DIA)(20-CM)
9G8909	COVER-TERMINAL (BLACK)	1
9X9825	TERMINAL-CABLE (00-GA, 1/2-IN SCREW)	1
0301705	TERMINAL-CABLE (00-GA, 5/16-IN SCREW)	1
1090887	SLEEVE (71-CM)
1311506	TERMINAL AS	1
2L8079	TERMINAL-RING (14-GA TO 16-GA, 3/8-IN SCREW)	1
1257874	TUBE-HEAT SHRINK (5.72-MM DIA)(3-CM)
1552270	KIT-CONNECTING PLUG (2-PIN)	1
3537505	32 BRACKET AS	2
8T3490	NUT-WELD (M10X1.5-THD)	1
1245815	33 BLOCK GP-JUNCTION	1
1400860	34 STRAP AS-GROUND	1
3853821	35 GROMMET	1
2V1771	36 GROMMET	5
3320013	38 CLIP (LOOP)	2
3E6753	39 GROMMET	1
3E6754	40 GROMMET	2
3V4791	41 GROMMET	3
4D6988	42 CLIP	1
4L3641	43 CLIP	4
4P7581	44 CLIP (LADDER)	1
5C7261	45 NUT (M8X1.25-THD)	4
5G6505	47 WASHER (25X38X14-MM THK)	2
3180820	48 GROMMET	15
6D4246	51 CLIP (LOOP)	4
6K8178	52 CLIP (LOOP)	1
4S1962	53 CLIP (LOOP)	11
7N0718	54 SWITCH GP-DISCONNECT	1
7U4891	55 SCREW (10-32X1-IN)	4
7U4892	56 SCREW (8-32X0.75-IN)	4
7X7729	57 WASHER (11X25X3-MM THK)	2
8S0948	59 CLIP	1
8S2634	60 COVER AS	1
8T0389	61 LOCKNUT (M10X1.5-THD)	2
8T4121	62 WASHER-HARD (11X21X2.5-MM THK)	32
8T4133	63 NUT (M10X1.5-THD)	7
8T4136	64 BOLT (M10X1.5X25-MM)	7
8T4137	65 BOLT (M10X1.5X20-MM)	18
8T4139	66 BOLT (M12X1.75X30-MM)	2
8T4182	67 BOLT (M10X1.5X45-MM)	1
8T4185	68 BOLT (M10X1.5X50-MM)	2
8T4223	69 WASHER-HARD (13.5X25.5X3-MM THK)	2
8T4224	70 WASHER-HARD (8.8X16X2-MM THK)	8
8T7547	71 BOLT (M8X1.25X30-MM)	4
9C5344	72 SPACER (10.5X20X18-MM THK)	1
9D3769	73 GROMMET	1
9R6414	74 ROD	2
5P4116	75 WASHER-HARD (8.8X20.5X2-MM THK)	1
8T4189	76 BOLT (M8X1.25X20-MM)	1
1211340	77 ANGLE AS	1
2W5331	BRACKET	1
8T3490	NUT-WELD (M10X1.5-THD)	1
1831025	78 STRAP AS	1
2751442	79 CLIP (TAB)	1
2751443	80 CLIP (SLOT)	1
3538733	81 BRACKET AS	2
1783336	82 NUT-HEX FLANGE (M8X1.25-THD)	3
