System And Components
435-9037 PIN & LINK GP-LIFT ARMS/N BL21-610; MD21-459
Group No: 435-9037
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 10 | |
| 3B8686 | 2 FITTING-GREASE (1/8-27 PTF) | 4 | |
| 3S8536 | 3 SPACER (0.406X0.656X0.38-IN THK) | 2 | |
| 1428832 | 4 PIN AS | 1 | |
| 1429091 | 5 PIN AS | 2 | |
| 1907992 | 6 SPACER (44.7X54.7X13.1-MM THK) | 2 | |
| 1919738 | 7 WASHER (13.8X70X5-MM THK) | 2 | |
| 1919739 | 8 BOLT-SOCKET HEAD (M10X1.5X40-MM) | 2 | |
| 2582679 | 9 PIN AS | 2 | |
| 2583451 | 10 PIN | 2 | |
| 2874215 | 11 WASHER (52.5X70X1-MM THK) | 8 | |
| 3455909 | 12 PIN AS | 4 | |
| 3455982 | 13 PIN | 2 | |
| 3456511 | 14 PIN AS | 2 | |
| 4223197 | 15 SUPPORT AS | 1 | |
| 5H3182 | PIN-SPRING | 1 | |
| 4223199 | 16 PIN AS | 2 | |
| 4358772 | 17 SPACER (45X69X25.4-MM THK) | 2 | |
| 4723748 | 18 LINK AS | 2 | |
| 9R0430 | 18A BUSHING | 2 | |
| 4522428 | 19 SPACER (52X70X4-MM THK) | 2 | |
| 1H8134 | 20 RING-RETAINING | 4 | |
| 3K4897 | 21 PIN-SPRING | 2 | |
| 4S5875 | 22 RING-RETAINING | 2 | |
| 5B0651 | 23 FITTING-STRAIGHT | 4 | |
| 5H9743 | 24 GROMMET | 1 | |
| 6N8863 | 25 WASHER (10.2X32X2.5-MM THK) | 8 | |
| 6V7700 | 26 RING-RETAINING | 4 | |
| 7X7729 | 27 WASHER (11X25X3-MM THK) | 4 | |
| 8T4136 | 28 BOLT (M10X1.5X25-MM) | 2 | |
| 8T4191 | 29 BOLT (M10X1.5X16-MM) | 10 | |
| 8T5439 | 30 WASHER-HARD (21.5X45X6-MM THK) | 4 |
