System And Components
170-7498 PUMP GP-FUEL INJECTIONS/N 3NW30314-UP
Group No: 170-7498
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0291 | 1 NUT (M8X1.25-THD) | 2 | |
| 6I0572 | 2 BOLT (M8X1.25X20-MM) | 4 | |
| 6I0631 | 3 BOLT (M6X1X12-MM) | 4 | |
| 6I0840 | 4 STUD (M8X20-MM) | 2 | |
| 0676998 | 5 NUT (3/8-24-THD) | 1 | |
| 0676999 | 6 FERRULE | 1 | |
| 1243533 | 7 DOWEL | 2 | |
| 1408713 | 8 CLIP | 2 | |
| 1408714 | 9 CLIP | 1 | |
| 1408718 | 10 WASHER | 4 | |
| 1707500 | 11 INJECTOR AS-FUEL | 4 | |
| 1472995 | 11A WASHER | 2 | |
| 1473043 | 12 GASKET | 1 | |
| 1473046 | 13 SEAL-O-RING | 4 | |
| 1473047 | 14 CLAMP | 4 | |
| 1531022 | 15 SPACER | 4 | |
| 1531153 | 16 LINE AS-FUEL INJECTION (CYLINDER ONE) | 1 | |
| 1531154 | 17 LINE AS-FUEL INJECTION (CYLINDER TWO) | 1 | |
| 1531155 | 18 LINE AS-FUEL INJECTION (CYLINDER THREE) | 1 | |
| 1531156 | 19 LINE AS-FUEL INJECTION (CYLINDER FOUR) | 1 | |
| 1925845 | 20 KIT-SHIM | 1 | |
| 1608657 | 21 LINE-FUEL (LEAK OFF) | 1 | |
| 1707499 | 22 PUMP GP-FUEL INJECTION | 1 | |
| 1460006 | 22A SCREW-PURGE | 1 | |
| 1460018 | 22B GASKET | 1 | |
| 1960975 | 22C BOLT | 1 | |
| 1960982 | 22D GASKET | 2 | |
| 2366650 | 23 COVER | 1 | |
| 1531023 | 24 NUT | 1 | |
| 1587931 | 25 LEVER | 1 | |
| 1730125 | 27 SPRING | 1 | |
| 1786226 | 28 ADJUSTER AS | 1 |
