System And Components
193-8375 WIRING GP-CABS/N CNC1-UP; CMP1-UP
Group No: 193-8375
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 16 | |
| 4B4863 | 2 WASHER (4.7X11X1.2-MM THK) | 2 | |
| 6I1418 | 3 SPACER (8.2X12.7X28.7-MM THK) | 3 | |
| 7G1060 | 4 STRAP AS-GROUND | 1 | |
| 8T8737 | 5 PLUG-SEAL | 13 | |
| 8T9655 | 6 MOUNT-ISOLATION | 6 | |
| 9R7941 | 7 SOCKET AS | 1 | |
| 1138490 | 8 FUSE (10-AMPERE)(GAGE PANEL) | 1 | |
| 1138490 | 8A FUSE (10-AMPERE)(INTERLOCK) | 1 | |
| 1138490 | 8B FUSE (10-AMPERE)(COLD START) | 1 | |
| 1138490 | 8C FUSE (10-AMPERE)(AUXILIARY HYDRAULIC) | 1 | |
| 1138490 | 8D FUSE (10-AMPERE)(KEY START SWITCH) | 1 | |
| 1138490 | 8E FUSE (10-AMPERE)(SPARE) | 1 | |
| 1138490 | 8F FUSE (10-AMPERE)(RH TAIL LAMP) | 1 | |
| 1138490 | 8G FUSE (10-AMPERE)(LH TAIL LAMP) | 1 | |
| 1138490 | 8H FUSE (10-AMPERE)(FUEL SHUTOFF) | 1 | |
| 1138491 | 9 FUSE (15-AMPERE)(REAR WORKING LAMP) | 1 | |
| 1138491 | 9A FUSE (15-AMPERE)(WIPER LEVER) | 1 | |
| 1284249 | 10 LOCKWASHER | 1 | |
| 1431974 | 11 RECEPTACLE | 4 | |
| 1464323 | 12 RELAY AS (12-VOLT)(PARKING BRAKE) | 1 | |
| 1544233 | 13 CONTROL GP-INTERLOCK | 1 | |
| 1880131 | 14 BRACKET AS | 1 | |
| 1908002 | 15 HARNESS AS-CAB (INTERLOCK) | 1 | |
| 1164159 | BASE | 1 | |
| 1252122 | CONNECTOR | 1 | |
| 1129609 | BLOCK-MICRORELAY | 1 | |
| 1249636 | BLOCK-MINIFUSE | 1 | |
| 1129610 | LOCK-MICRORELAY | 1 | |
| 1249637 | LOCK-MINIFUSE | 1 | |
| 1116816 | LOCK | 1 | |
| 8T8737 | PLUG-SEAL | 24 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 7T0094 | SOCKET-CONNECTOR (12-GA TO 14-GA) | 6 | |
| 9W0844 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 9X3402 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 115 | |
| 1261768 | SOCKET-CONNECTOR (14-GA TO 16-GA) | 3 | |
| 8L8413 | STRAP-CABLE (WHITE) | 11 | |
| 1129611 | TERMINAL-BLADE (18-GA TO 20-GA) | 8 | |
| 1129612 | TERMINAL-BLADE (16-GA TO 18-GA) | 12 | |
| 1164160 | TERMINAL-BLADE (12-GA TO 14-GA) | 3 | |
| 1164161 | TERMINAL-BLADE (16-GA TO 18-GA) | 14 | |
| 3E9179 | TERMINAL-RECEPTACLE (14-GA TO 18-GA) | 4 | |
| 1116792 | TERMINAL-RECEPTACLE (18-GA TO 20-GA) | 3 | |
| 1193662 | TUBE-HEAT SHRINK (10.85-MM DIA)(20-CM) | ||
| 1257874 | TUBE-HEAT SHRINK (5.72-MM DIA)(55-CM) | ||
| 1257875 | TUBE-HEAT SHRINK (7.44-MM DIA)(5-CM) | ||
| 1938374 | 16 COVER GP-FUSE PANEL | 1 | |
| 2110052 | 17 NUT (1-11/16-18-THD) | 1 | |
| 1114627 | 18 SCREW-MACHINE (M6X1X30-MM) | 4 | |
| 1950936 | 19 INSERT-THREADED (M6X1-THD) | 8 | |
| 1028803 | 20 KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028804 | 21 KIT-RECEPTACLE (4-PIN) | 1 | |
| 1028805 | 22 KIT-RECEPTACLE (6-PIN) | 1 | |
| 1028806 | 23 KIT-RECEPTACLE (8-PIN) | 1 | |
| 4P7581 | 24 CLIP (LADDER) | 1 | |
| 4P8134 | 25 CLIP (LADDER) | 2 | |
| 5C7261 | 26 NUT (M8X1.25-THD) | 3 | |
| 5C8312 | 27 NUT (M4X0.7-THD) | 2 | |
| 5C9553 | 28 BOLT (M6X1X16-MM) | 6 | |
| 7G7053 | 29 GROMMET | 1 | |
| 7X0579 | 30 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 32 NUT (M10X1.5-THD) | 1 | |
| 8T4205 | 33 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 9X1046 | 34 SCREW (M4X0.7X18-MM) | 2 | |
| 9X2042 | 35 SCREW-TRUSS HEAD (M6X1X12-MM) | 6 | |
| 9X6165 | 36 WASHER (6.5X22X2.5-MM THK) | 4 | |
| 9X2092 | 37 TRIM-EDGE (21-CM) | ||
| 1464323 | 38 RELAY AS (12-VOLT)(ARMREST INDICATOR) | 1 |
