System And Components
422-1729 LINES GP-PUMP -IMPLEMENTPART OF 422-3266 HYDRAULIC AR, 450-8269, 450-8270 OPTION AR-LAND MANAGEMENT
Group No: 422-1729
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4231982 | 1 HOSE (25-IN) | ||
| 9U6995 | 2 FITTING GP-HYDRAULIC (CLEAN GAS INDUCTION) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 1503024 | 4 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P4924 | ELBOW | 1 | |
| 2042281 | 5 STRAP-CABLE | 2 | |
| 2376094 | 6 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 2376095 | CONNECTOR | 1 | |
| 2416215 | 7 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8076 | ELBOW | 1 | |
| 2644297 | 8 SENSOR AS-TEMPERATURE (2-PIN)(HYDRAULIC OIL) | 1 | |
| 1376645 | PAD-CONNECTOR | 1 | |
| 2905562 | 9 MOUNT (DUAL SWIVEL) | 1 | |
| 3233308 | 10 CAP | 4 | |
| 3295510 | 11 CONNECTOR AS | 1 | |
| 8T0198 | CONNECTOR | 1 | |
| 2287093 | SEAL-O-RING | 1 | |
| 2385084 | SEAL-O-RING | 1 | |
| 4358879 | 12 HOSE | 1 | |
| 3737039 | 13 VALVE GP-CHECK (PUMP CASE DRAIN) | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 3888139 | 14 HOSE | 1 | |
| 4229407 | 15 ADAPTER AS | 1 | |
| 4223149 | SEAL-O-RING | 1 | |
| 4223137 | 16 BRACKET AS | 1 | |
| 4223549 | 17 HOSE AS | 1 | |
| 4226637 | 18 HOSE AS | 1 | |
| 4226731 | 19 HOSE AS | 1 | |
| 4262783 | 20 TUBE AS | 1 | |
| 4330933 | 21 CLAMP | 2 | |
| 4488823 | 22 HOSE AS | 1 | |
| 1106349 | 24 FITTING AS (QUICK DISCONNECT) | 1 | |
| 1488336 | 25 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488352 | 26 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9854 | ELBOW (SWIVEL) | 1 | |
| 1488357 | 27 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488361 | 28 ELBOW AS (90-DEG) | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488371 | 29 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8C8988 | ELBOW | 1 | |
| 1488378 | 30 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488411 | 31 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1645567 | 33 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1783620 | 34 STRAP-DUAL CLAMP | 4 | |
| 1138694 | 35 BOLT (M6X1X20-MM) | 1 | |
| 2663315 | 36 BOLT-FLANGE HEAD (M8X1.25X25.5-MM) | 1 | |
| 3436821 | 37 CLAMP-BAND | 2 | |
| 3474163 | 38 CLAMP-BAND | 2 | |
| 2S3440 | 39 CLAMP-HOSE | 1 | |
| 3737623 | 40 CLAMP-BAND | 2 | |
| 3K0360 | 41 SEAL-O-RING | 1 | |
| 6V0852 | 43 CAP-DUST | 3 | |
| 7K1181 | 44 STRAP-CABLE | 1 | |
| 8T4956 | 45 BOLT (M12X1.75X35-MM) | 4 | |
| 8T4223 | 46 WASHER-HARD (13.5X25.5X3-MM THK) | 4 |
