System And Components
392-0624 TURBOCHARGER GPS/N CNW1-UP
Group No: 392-0624
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1336106 | 1 BOLT (M6X1X16-MM) | 2 | |
| 4653480 | 2 BOLT | 1 | |
| 4890637 | 3 CLIP | 6 | |
| 3866368 | 4 GASKET | 1 | |
| 3866453 | 5 PIPE | 1 | |
| 3877697 | 6 GASKET | 1 | |
| 4680577 | 7 PIPE AS | 1 | |
| 3878113 | 8 TUBE AS | 1 | |
| 3861911 | 8A SEAL | 2 | |
| 3891934 | 9 NUT | 2 | |
| 4626745 | 10 WASHER | 2 | |
| 3902381 | 11 PIPE | 1 | |
| 3902382 | 12 PIPE | 1 | |
| 3902468 | 15 GASKET | 1 | |
| 4981551 | 16 TURBOCHARGER AS | 1 | |
| 3920743 | 17 BRACKET AS | 1 | |
| 3902397 | 17A CLIP | 2 | |
| 4355729 | 20 COVER GP-ENGINE OIL COOLER | 1 | |
| 1127704 | 21 BOLT (M6X1X30-MM) | 3 | |
| 1243815 | 22 BOLT (M8X1.25X16-MM) | 1 | |
| 6I0846 | 23 BOLT (M6X1X14-MM) | 3 |
