System And Components
292-8768 PUMP GP-PISTON -IMPLEMENT, PILOTS/N RWE1-UP
Group No: 292-8768
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4215 | 1 SPACER | 1 | |
| 8J0101 | 2 PLATE-NOTICE (HYDRAULIC OIL FILL) | 1 | |
| 0964389 | 3 SPRING | 9 | |
| 1297853 | 4 PLATE | 1 | |
| 1297921 | 5 RING-RETAINING | 1 | |
| 3412862 | 6 SEAL-LIP TYPE | 2 | |
| 1297927 | 7 BEARING | 1 | |
| 1505782 | 8 COVER | 2 | |
| 1733427 | 9 GUIDE-BALL | 1 | |
| 2458095 | 11 PLATE-ADAPTER | 1 | |
| 2546555 | 12 BLOCK | 1 | |
| 2560083 | 13 BARREL AS-PUMP | 1 | |
| 2567485 | 14 PISTON AS | 1 | |
| 2637474 | 15 SET-BEARING | 1 | |
| 2733591 | 16 SHAFT-PUMP (17-TEETH) | 1 | |
| 2923264 | 17 SEAL-O-RING | 1 | |
| 3582556 | 18 BODY AS | 1 | |
| 0941875 | 18A DOWEL | 2 | |
| 1241555 | 18B PLUG | 2 | |
| 1297979 | 18C DOWEL | 2 | |
| 1920573 | 18D PIN-DOWEL | 2 | |
| 2928771 | 19 CASE | 1 | |
| 3666195 | 20 HEAD GP-PUMP | 1 | |
| 0673161 | 21 RING-RETAINING | 1 | |
| 0941875 | 22 DOWEL | 1 | |
| 0941883 | 23 PLUG | 1 | |
| 0950673 | 24 BOLT-SOCKET HEAD (M12X1.75X60-MM) | 4 | |
| 0950946 | 25 RING-RETAINING | 1 | |
| 0941882 | 26 PLUG | 1 | |
| 1178801 | 27 SEAL-O-RING | 1 | |
| 1899763 | 29 SEAL-O-RING | 1 | |
| 1931736 | 30 SEAL-O-RING | 2 | |
| 2366919 | 31 SEAL-O-RING | 1 | |
| 3739516 | 32 SWASHPLATE AS | 1 | |
| 0941875 | DOWEL | 1 | |
| 1733428 | BUSHING | 1 | |
| 2426803 | PIN-DOWEL | 2 | |
| 3739518 | 33 BEARING AS (ROCKER) | 2 | |
| 3D2824 | 34 SEAL-O-RING | 2 | |
| 3J1907 | 35 SEAL-O-RING | 1 | |
| 3K0360 | 36 SEAL-O-RING | 3 | |
| 4B4158 | 37 SCREW-DRIVE (NO 4X0.25-IN) | 4 | |
| 4I1022 | 38 ORIFICE | 1 | |
| 6V3907 | 39 SEAL-O-RING (FUEL FILTER) | 1 | |
| 6V8200 | 40 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 2 | |
| 8T4136 | 41 BOLT (M10X1.5X25-MM) | 8 | |
| 8T4140 | 42 BOLT (M16X2X60-MM) | 4 | |
| 9S4183 | 43 PLUG (1-1/16-12-THD) | 2 | |
| 9S4185 | 44 PLUG (3/4-16-THD) | 2 | |
| 9S8004 | 45 PLUG (9/16-18-THD) | 1 | |
| 9S8005 | 46 PLUG (3/4-16-THD) | 1 |
