System And Components
447-4929 PLANETARY GP-TRANSMISSIONS/N NA41-UP
Group No: 447-4929
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1131830 | 1 PLATE AS | 1 | |
| 8T1445 | DOWEL | 2 | |
| 1444284 | 2 RING-LOCK | 3 | |
| 5440585 | 3 HOUSING AS-CLUTCH | 1 | |
| 3P7009 | PLUG-CUP | 1 | |
| 1S5596 | 4 RETAINER | 1 | |
| 3T4377 | 5 SEAL-RING | 2 | |
| 5L1941 | 6 SPRING | 5 | |
| 6I8510 | 7 HOUSING AS-CLUTCH | 1 | |
| 6B6863 | PIN-SPRING | 1 | |
| 6P7704 | CARRIER-RING | 1 | |
| 6Y1602 | 8 COUPLING | 1 | |
| 6Y4819 | 9 CARRIER-PLANETARY | 1 | |
| 7G2516 | 10 GEAR-PLANETARY (24-TEETH) | 6 | |
| 7G2830 | 11 RING-SEAL | 2 | |
| 7G3975 | 12 RING-RETAINING | 1 | |
| 7G5670 | 13 SEAL-RING | 1 | |
| 7G6355 | 14 GEAR-RING (90-TEETH) | 1 | |
| 7G7218 | 15 CARRIER-PLANETARY | 1 | |
| 7G7724 | 16 PISTON-CLUTCH | 1 | |
| 7T9370 | 17 GEAR-SUN (51-TEETH) | 1 | |
| 8E8299 | 18 DISC-THRUST | 14 | |
| 8E8304 | 19 DISC-THRUST | 12 | |
| 8E8305 | 20 DISC-THRUST | 6 | |
| 8P1916 | 21 GEAR-PLANETARY (20-TEETH) | 3 | |
| 8P1918 | 22 GEAR-PLANETARY (20-TEETH) | 4 | |
| 8P1919 | 23 GEAR-PLANETARY (27-TEETH) | 3 | |
| 8P1948 | 24 GEAR-RING (88-TEETH) | 1 | |
| 8P1964 | 25 PLATE-CLUTCH | 2 | |
| 8P2042 | 26 SHAFT-PLANETARY | 4 | |
| 8P2053 | 27 SEAL-RING | 1 | |
| 9G0289 | 28 SHAFT-PLANETARY | 3 | |
| 9G0290 | 29 HUB-CLUTCH | 1 | |
| 9G8020 | 30 PLATE-RETAINER | 1 | |
| 9P7757 | 31 GEAR-SUN (42-TEETH) | 1 | |
| 9P8116 | 32 CARRIER-PLANETARY | 1 | |
| 9P8516 | 33 GEAR-RING (85-TEETH) | 1 | |
| 9P8623 | 34 SHAFT-PLANETARY | 3 | |
| 9P8626 | 35 GEAR-SUN (42-TEETH) | 1 | |
| 9P9031 | 36 GEAR-SUN (47-TEETH) | 1 | |
| 9W8433 | 37 SHAFT AS-OUTPUT | 1 | |
| 9G6743 | 37A BUSHING | 1 | |
| 9G6744 | 37B BUSHING | 1 | |
| 5M3038 | SEAL-O-RING | 1 | |
| 9W8437 | 38 GEAR AS-SUN (32-TEETH) | 1 | |
| 5M3038 | SEAL-O-RING | 1 | |
| 1123818 | 39 SHAFT AS-INPUT | 1 | |
| 8M5010 | SEAL-O-RING | 1 | |
| 1125585 | 40 SHAFT-PLANETARY | 3 | |
| 1128041 | 41 CARRIER-PLANETARY | 1 | |
| 1131832 | 42 HOUSING-CLUTCH | 1 | |
| 1155570 | 43 GEAR-RING (90-TEETH) | 1 | |
| 1155572 | 44 PLATE-CLUTCH | 14 | |
| 1166653 | 45 HOUSING AS | 1 | |
| 1A2223 | DOWEL | 4 | |
| 1223768 | 46 GEAR-TRANSFER (58-TEETH) | 1 | |
| 1314091 | 47 SEAL-RING | 1 | |
| 1862461 | 48 GEAR-RING (90-TEETH) | 1 | |
| 1957876 | 49 HOUSING AS | 1 | |
| 1A2223 | DOWEL | 2 | |
| 1J5353 | PIN-SPRING | 5 | |
| 1957877 | 50 MANIFOLD AS | 1 | |
| 1A2223 | DOWEL | 1 | |
| 3P7009 | PLUG-CUP | 1 | |
| 1957880 | MANIFOLD | 1 | |
| 3709775 | 51 DISC-FRICTION | 14 | |
| 3709778 | 52 DISC-FRICTION | 3 | |
| 3766663 | 53 PISTON | 4 | |
| 0616711 | 54 RING-RETAINING | 1 | |
| 9U9550 | 55 PLATE-CLUTCH | 1 | |
| 0673161 | 56 RING-RETAINING | 1 | |
| 0688093 | 57 RING-RETAINING | 1 | |
| 1124511 | 58 PIN-SPRING | 3 | |
| 1168230 | 59 ROD | 5 | |
| 1168234 | 60 DAMPER-BOLT | 4 | |
| 1209486 | 61 BOLT-SPECIAL (M16X2X420-MM) | 4 | |
| 1650142 | 62 WASHER-HARD (14.8X27X3-MM THK) | 7 | |
| 1L7388 | 63 RING-RETAINING | 1 | |
| 2629948 | 64 BOLT-SPECIAL | 5 | |
| 2744483 | 65 BOLT (M12X1.75X100-MM) | 2 | |
| 2S0669 | 66 BEARING | 8 | |
| 2S1382 | 67 SPRING | 10 | |
| 3H0107 | 68 SEAL-O-RING | 4 | |
| 3S2708 | 69 PIN-SPRING | 10 | |
| 3S9896 | 70 SEAL-O-RING | 1 | |
| 4F2129 | 71 BALL BEARING | 1 | |
| 4S5924 | 72 SEAL-O-RING | 4 | |
| 5D2989 | 73 BEARING | 3 | |
| 5K8591 | 74 BEARING-OUTER | 1 | |
| 5M3038 | 75 SEAL-O-RING | 2 | |
| 5M6126 | 76 BEARING AS-ROLLER | 6 | |
| 5P3930 | 77 BEARING AS-ROLLER | 3 | |
| 5P5296 | 78 RING-RETAINING | 2 | |
| 5P5297 | 79 RING-RETAINING (EXTERNAL) | 1 | |
| 5P8194 | 80 RING-RETAINING | 1 | |
| 6V0473 | 81 RING-RETAINING | 3 | |
| 6V2478 | 82 RING-RETAINING | 1 | |
| 6V4350 | 83 RACE-ROLLER BEARING | 1 | |
| 6V4351 | 84 PLATE-INNER RACE | 1 | |
| 7G2343 | 85 SPRING-DISC | 3 | |
| 7J6580 | 86 RING-RETAINING | 1 | |
| 7T8816 | 87 BALL BEARING | 3 | |
| 8D9739 | 88 SEAL-RING | 1 | |
| 8H5352 | 89 BALL BEARING | 1 | |
| 8M5010 | 90 SEAL-O-RING | 1 | |
| 8M5255 | 91 SEAL-O-RING | 1 | |
| 8P2019 | 92 RING-SEAL | 4 | |
| 8P2022 | 93 RING-SEAL | 4 | |
| 8P2023 | 94 RING-SEAL | 1 | |
| 8T0106 | 95 BOLT (M12X1.75X100-MM) | 1 | |
| 9X8268 | 96 WASHER (17.5X30X3.5-MM THK) | 4 |
