System And Components
123-0278 CONTROL GP-TRANSMISSION HYDS/N 1JY2709-2770
Group No: 123-0278
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1230283 | 1 VALVE GP-TRANSMISSION CONTROL | 1 | |
| 6B1557 | 2 BOLT (3/8-16X7.5-IN) | 4 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9S4183 | 4 PLUG (1-1/16-12-THD) | 1 | |
| 3D2824 | 5 SEAL-O-RING | 1 | |
| 2S5717 | 6 LOCKNUT (3/8-16-THD) | 3 | |
| 1F5842 | 7 BOLT (5/16-18X3.25-IN) | 1 | |
| 1194341 | 8 GEAR AS (28 TEETH) | 1 | |
| 9P9650 | DOWEL | 1 | |
| 1216543 | 9 CAM | 1 | |
| 9W6376 | 10 LEVER | 1 | |
| 0S1617 | 11 BOLT (5/16-18X0.75-IN) | 1 | |
| 5P4116 | 12 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 1316007 | 13 SECTOR | 1 | |
| 8E9060 | 14 PIN-CAM | 1 | |
| 9U9633 | 15 ROD | 3 | |
| 2160630 | 16 SPRING AS | 1 | |
| 1S3206 | BEARING AS-NEEDLE | 2 | |
| 8P4764 | PIN | 1 | |
| 1B7182 | 17 BOLT (5/16-18X1.25-IN) | 1 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 0314155 | 19 LOCKNUT (5/16-18-THD) | 1 | |
| 9N0869 | 20 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 4B3388 | 21 BOLT (5/16-18X1.125-IN) | 2 | |
| 9U9338 | 22 CYLINDER GP-SHIFT | 1 | |
| 9G9150 | 23 CLIP (TAB) | 2 | |
| 1A2029 | 24 BOLT (3/8-16X1.125-IN) | 7 | |
| 9W6375 | 25 LEVER | 1 | |
| 9G7353 | 26 PIN | 2 | |
| 8L5922 | 27 BOLT-LOCKING (5/16-18X0.563-IN) | 1 | |
| 1418466 | 28 RETAINER | 1 | |
| 6P4977 | 29 SLEEVE | 2 | |
| 8M4432 | 30 SEAL-O-RING | 4 | |
| 1B9575 | 31 BOLT (5/16-18X1.56-IN) | 2 | |
| 1270813 | 32 BLOCK | 1 | |
| 1175993 | 33 BLOCK | 1 | |
| 2J6274 | 34 SEAL-O-RING | 2 | |
| 4D0514 | 35 PLUG-PIPE | 1 | |
| 8M4986 | 36 SEAL-O-RING | 1 | |
| 0S1594 | 37 BOLT (3/8-16X1-IN) | 4 | |
| 8S5575 | 38 SEAL-LIP TYPE | 1 | |
| 6N8863 | 39 WASHER (10.2X32X2.5-MM THK) | 1 | |
| 8S7803 | 40 RING-RETAINING | 1 | |
| 9S8005 | 41 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 42 SEAL-O-RING | 1 | |
| 1988762 | 43 SENSOR GP-POSITION | 1 | |
| 9U9371 | 44 BOLT-PIVOT | 1 | |
| 2B2695 | 45 BOLT (5/16-18X0.875-IN) | 3 | |
| 6H5829 | 46 RING-RETAINING | 2 | |
| 9W6374 | 47 FOLLOWER-CAM | 2 | |
| 3H1461 | 48 SEAL-O-RING | 2 | |
| 3J1907 | 49 SEAL-O-RING | 2 | |
| 9U9368 | 50 PLUG AS | 1 | |
| 9S8004 | 51 PLUG (9/16-18-THD) | 1 | |
| 1230281 | 52 HOUSING AS | 1 | |
| 4F2609 | DOWEL | 2 | |
| 9U9372 | 53 GASKET | 1 | |
| 0S1618 | 54 BOLT (5/16-18X1-IN) | 10 | |
| 1194347 | 55 COVER AS | 1 | |
| 6V3545 | BEARING-ROLLER | 1 | |
| 1197316 | BEARING AS-NEEDLE | 1 | |
| 1209288 | 56 HARNESS AS-TRANSMISSION | 1 | |
| 0S0509 | 57 BOLT (3/8-16X0.75-IN) | 2 | |
| 3D4197 | 58 COVER | 1 | |
| 8M4988 | 59 SEAL-O-RING | 1 | |
| 6T5132 | 60 COVER | 1 | |
| 6T5133 | 61 GASKET | 1 | |
| 8E3077 | 62 ADAPTER | 2 | |
| 8E3078 | 63 SLEEVE | 1 | |
| 6V4365 | 64 SEAL-O-RING | 4 | |
| 1198096 | 65 CONNECTOR | 2 | |
| 4J7533 | 66 SEAL-O-RING | 2 | |
| 1189464 | 67 HOSE AS | 1 | |
| 1194345 | 68 COUPLING AS | 1 | |
| 1305620 | 69 WASHER-THRUST (23X37X1.25-MM THK) | 1 | |
| 1316776 | 70 SLEEVE | 1 | |
| 1T0738 | 71 WASHER (8.4X19X1.83-MM THK) | 3 |
