System And Components
9U-9491 CONTROL GP-TRANSMISSION HYDS/N 6RY568-99999; 8LY568-UP
Group No: 9U-9491
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1374919 | 1 VALVE GP-TRANSMISSION CONTROL | 1 | |
| 5F4899 | 2 BOLT (3/8-16X5.5-IN) | 4 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 6 | |
| 9S4181 | 4 PLUG (1-5/16-12-THD) | 1 | |
| 7M8485 | 5 SEAL-O-RING | 1 | |
| 2S5717 | 6 LOCKNUT (3/8-16-THD) | 3 | |
| 1F5842 | 7 BOLT (5/16-18X3.25-IN) | 1 | |
| 1194341 | 8 GEAR AS | 1 | |
| 9P9650 | DOWEL | 1 | |
| 9G7351 | 9 ROD | 2 | |
| 9W6376 | 10 LEVER | 1 | |
| 0S1617 | 11 BOLT (5/16-18X0.75-IN) | 6 | |
| 5P4116 | 12 WASHER-HARD (8.8X20.5X2-MM THK) | 4 | |
| 1316007 | 13 SECTOR | 1 | |
| 8E9060 | 14 PIN-CAM | 1 | |
| 9U9633 | 15 ROD | 1 | |
| 1194348 | 16 CAM | 1 | |
| 2160630 | 17 SPRING AS | 1 | |
| 1S3206 | BEARING AS-NEEDLE | 2 | |
| 8P4764 | PIN | 1 | |
| 1B7182 | 18 BOLT (5/16-18X1.25-IN) | 1 | |
| 9M1974 | 19 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 0314155 | 20 LOCKNUT (5/16-18-THD) | 1 | |
| 9N0869 | 21 WASHER-HARD (8.8X25.5X2-MM THK) | 1 | |
| 4B3388 | 22 BOLT (5/16-18X1.125-IN) | 2 | |
| 9U9338 | 23 CYLINDER GP-SHIFT | 1 | |
| 9G9150 | 24 CLIP | 2 | |
| 1A2029 | 25 BOLT (3/8-16X1.125-IN) | 3 | |
| 9W6375 | 26 LEVER | 1 | |
| 9G7353 | 27 PIN | 2 | |
| 8L5922 | 28 BOLT-LOCKING (5/16-18X0.563-IN) | 1 | |
| 1418466 | 29 RETAINER | 1 | |
| 6P4977 | 30 SLEEVE | 2 | |
| 8M4432 | 31 SEAL-O-RING | 4 | |
| 1B9575 | 32 BOLT (5/16-18X1.56-IN) | 2 | |
| 1270813 | 33 BLOCK | 1 | |
| 1175993 | 34 BLOCK | 1 | |
| 2J6274 | 35 SEAL-O-RING | 2 | |
| 4D0514 | 36 PLUG-PIPE | 1 | |
| 8M4986 | 37 SEAL-O-RING | 1 | |
| 0S1594 | 38 BOLT (3/8-16X1-IN) | 4 | |
| 8S5575 | 39 SEAL-LIP TYPE | 1 | |
| 6N8863 | 40 WASHER (10.2X32X2.5-MM THK) | 1 | |
| 8S7803 | 41 RING-RETAINING | 1 | |
| 9S8005 | 42 PLUG (3/4-16-THD) | 1 | |
| 3K0360 | 43 SEAL-O-RING | 1 | |
| 1988762 | 44 SENSOR GP-POSITION | 1 | |
| 9U9371 | 45 BOLT-PIVOT | 1 | |
| 2B2695 | 46 BOLT (5/16-18X0.875-IN) | 3 | |
| 6H5829 | 47 RING-RETAINING | 2 | |
| 9W6374 | 48 FOLLOWER-CAM | 2 | |
| 3H1461 | 49 SEAL-O-RING | 2 | |
| 3J1907 | 50 SEAL-O-RING | 2 | |
| 9U9368 | 51 PLUG AS | 1 | |
| 9S8004 | 52 PLUG (9/16-18-THD) | 1 | |
| 0S1588 | 53 BOLT (3/8-16X1.25-IN) | 4 | |
| 9U9363 | 54 HOUSING AS | 1 | |
| 4F2609 | DOWEL | 2 | |
| 9U9372 | 55 GASKET | 1 | |
| 0S1618 | 56 BOLT (5/16-18X1-IN) | 10 | |
| 1194347 | 57 COVER AS | 1 | |
| 1197316 | BEARING AS-NEEDLE | 1 | |
| 6V3545 | BEARING-ROLLER | 1 | |
| 1209288 | 58 HARNESS AS-TRANSMISSION | 1 | |
| 0S0509 | 59 BOLT (3/8-16X0.75-IN) | 2 | |
| 3D4197 | 60 COVER | 1 | |
| 8M4988 | 61 SEAL-O-RING | 1 | |
| 6T5132 | 62 COVER | 1 | |
| 6T5133 | 63 GASKET | 1 | |
| 8E3077 | 64 ADAPTER | 2 | |
| 1179987 | 65 SLEEVE | 2 | |
| 6V4365 | 66 SEAL-O-RING | 4 | |
| 1198096 | 67 CONNECTOR | 2 | |
| 4J7533 | 68 SEAL-O-RING | 2 | |
| 1189464 | 69 HOSE AS | 1 | |
| 1194345 | 70 COUPLING AS | 1 | |
| 1305620 | 71 WASHER-THRUST (23X37X1.25-MM THK) | 1 | |
| 1T0738 | 72 WASHER (8.4X19X1.83-MM THK) | 3 |
