System And Components
398-3585 MODULE AR-CLEAN EMISSIONSS/N TGM1-UP
Group No: 398-3585
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0254 | 1 BOLT (M8X1.25X30-MM) | 6 | |
| 6I0654 | 2 BOLT (M10X1.5X25-MM) | 14 | |
| 1004841 | 3 BOLT (M6X1X10-MM) | 3 | |
| 1068916 | 4 BOLT (M6X1X16-MM) | 2 | |
| 1535592 | 5 NUT (M8X1.25-THD) | 12 | |
| 1536855 | 6 CLAMP-HOSE | 2 | |
| 1958372 | 7 CLIP | 1 | |
| 2390232 | 8 STUD (M8X1.25X31-MM) | 2 | |
| 4350208 | 9 GASKET | 2 | |
| 4237726 | 10 GASKET | 4 | |
| 4894658 | 11 SENSOR (DPF PRESSURE DIFFERENTIAL) | 1 | |
| 4238348 | 12 SENSOR-TEMPERATURE (DPF) | 1 | |
| 4238351 | 13 SENSOR-TEMPERATURE | 1 | |
| 4238353 | 14 SENSOR-TEMPERATURE | 1 | |
| 4248601 | 15 CLIP | 2 | |
| 4249850 | 16 CATALYST GP | 1 | |
| 4311821 | 18 ELBOW | 1 | |
| 4426144 | 19 BRACKET | 1 | |
| 4472570 | 20 EXHAUST GP | 1 | |
| 4531447 | 21 BRACKET AS | 1 | |
| 4531448 | 22 BRACKET AS | 1 | |
| 4534268 | 23 BRACKET | 1 | |
| 4538755 | 24 HOSE | 1 | |
| 4656981 | 25 PIPE | 1 | |
| 4656982 | 26 PIPE | 1 | |
| 4656994 | 27 BRACKET | 1 | |
| 4656996 | 28 BOLT-BANJO (M12X1.25X21-MM) | 2 | |
| 4664846 | 29 HOSE | 1 | |
| 4664847 | 30 HOSE | 1 | |
| 8T3993 | 31 CLAMP-HOSE | 1 |
