System And Components
541-2788 HOUSING GP-FRONTPART OF 532-8604 HOUSING GP-FRONT
Group No: 541-2788
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5596261 | 1 HOUSING-FRONT | 1 | |
| 4237724 | 2 GASKET | 1 | |
| 3355578 | 3 BRACKET | 1 | |
| 1068916 | 4 BOLT (M6X1X16-MM) | 4 | |
| 1622207 | 5 NUT | 1 | |
| 1335512 | 6 NUT | 1 | |
| 3694486 | 7 BOLT (M6X1X35-MM) | 2 | |
| 3340732 | 8 ARM | 1 | |
| 2897507 | 9 SEAL-O-RING | 1 | |
| 1535592 | 10 NUT (M8X1.25-THD) | 1 | |
| 3309189 | 11 PLUG | 1 | |
| 1541673 | 12 PIN | 1 | |
| 1537978 | 13 SEAL | 1 | |
| 1536415 | 14 WASHER | 1 | |
| 5039731 | 15 SHROUD | 1 | |
| 5029478 | 16 NUT | 1 | |
| 4950737 | 17 BOLT | 1 | |
| 3081882 | 18 SPRING | 1 | |
| 5025421 | 19 PIN | 1 | |
| 5039707 | 20 CAP | 1 | |
| 1652140 | 21 BOLT AS | 4 | |
| 1535962 | 22 BOLT AS | 4 | |
| 1622208 | 23 CAP | 1 | |
| 1535960 | 24 NUT (M6X1-THD) | 1 | |
| 1831164 | 25 STUD (M6X1X68-MM) | 1 | |
| 2897503 | 26 GASKET | 1 | |
| 2886593 | 27 SEAL | 1 | |
| 4831214 | 28 CAP | 1 | |
| 1535394 | 29 DOWEL | 2 | |
| 3135832 | 30 BOLT AS | 1 | |
| 1919297 | 30A NUT (M10X1.25-THD) | 1 | |
| 1537987 | 30B WASHER | 1 | |
| 3135833 | 30C SPRING | 1 | |
| 4237554 | 31 CAP | 1 | |
| 2177115 | 31A CAP (TAMPER RESISTANT) | 1 |
