System And Components
540-6521 CYLINDER BLOCK GPPART OF 564-7740, 564-7743 ENGINE AR-PRIMARY
Group No: 540-6521
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1535391 | 1 PLUG | 1 | |
| 1536850 | 2 COLLAR | 1 | |
| 2211136 | 3 PLUG (BLANKING) | 5 | |
| 1535381 | 4 PLUG | 1 | |
| 1535392 | 5 BEARING | 1 | |
| 4870157 | 6 PIN-SPRING | 2 | |
| 1535385 | 7 PLUG | 1 | |
| 1535393 | 8 DOWEL | 2 | |
| 2109587 | 9 DOWEL | 2 | |
| 1536848 | 10 COVER | 1 | |
| 1536849 | 11 SPRING | 1 | |
| 1536851 | 12 CLIP | 1 | |
| 1536853 | 13 SEAL-O-RING | 1 | |
| 1536879 | 14 STUD-HOLLOW | 1 | |
| 1541942 | 15 VALVE-RELIEF | 1 | |
| 1604150 | 16 SHIM (0.1-MM THK) | 1 | |
| 1604151 | 17 SHIM (0.15-MM THK) | 1 | |
| 1604152 | 18 SHIM (0.2-MM THK) | 1 | |
| 1604153 | 19 SHIM (0.5-MM THK) | 1 | |
| 2914741 | 20 TUBE (OIL) | 1 | |
| 1535414 | 21 SEAL | 1 | |
| 3260082 | SLEEVE | ||
| 3084180 | 22 BUSHING | 1 | |
| 2886542 | 23 SHAFT (IDLE) | 1 | |
| 1535592 | NUT (M8X1.25-THD) | 1 | |
| 2587291 | 24 PLUG-PIPE | 1 | |
| 1535387 | 25 PLUG | 4 | |
| 5366614 | 26 ROTOR | 1 | |
| 1535390 | 27 BALL BEARING | 1 | |
| 5426232 | 28 BLOCK AS | 1 | |
| 2886537 | 28A CAP | 2 | |
| 2886538 | 28B PLUG | 4 | |
| 2886539 | CAP | 1 | |
| 5612379 | 29 GEAR AS-IDLER | 1 | |
| 1541677 | BUSHING | 3 | |
| 1541679 | SPRING | 1 | |
| 1535409 | 30 CLIP | 1 | |
| 1537985 | 31 WASHER | 1 | |
| 3393015 | KIT-FRONT GEAR (IDLER) | 1 |
