System And Components
145-8901 BATTERY & WIRING GPS/N BFA1-1757; BDH1-788; 3YW1830-3339
Group No: 145-8901
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3T3132 | 1 SWITCH AS-LIMIT (HIGH SPEED TRAVEL) | 1 | |
| 2H3922 | LOCKWASHER | 1 | |
| 6V8363 | SCREW (10-32X0.312-IN) | 2 | |
| 6V8370 | NUT-HEX (3/4-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 2 | |
| 9X0199 | BOOT-SWITCH | 1 | |
| 7T0635 | 2 HORN AS (12-VOLT) | 1 | |
| 8C7581 | SCREW-MACHINE (M4X0.7X8-MM) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 0966166 | WASHER-HARD (4.5X9X1-MM THK) | 2 | |
| 8I4641 | 3 STRAP-GROUND | 1 | |
| 8T8799 | 4 BOOT (RED) | 1 | |
| 9W1442 | 5 FUSE (10-AMPERE) | 9 | |
| 0897365 | 6 WASHER (7X24X10-MM THK) | 1 | |
| 1068704 | 7 SUPPRESSOR AS-ARC | 1 | |
| 1092350 | 8 SWITCH AS-ROCKER (WARNING BEACON, POWER RECEP)(WIPER) | 1 | |
| 1151615 | 9 RELAY AS (12-VOLT) | 6 | |
| 1200667 | 10 SENDER-TEMPERATURE (COOLANT) | 1 | |
| 1384923 | 11 SHAFT | 1 | |
| 1394972 | 12 SPACER AS | 1 | |
| 1432267 | 13 GAUGE GP-CLUSTER | 1 | |
| 1442317 | 14 BOOT | 1 | |
| 1442321 | 15 PLATE | 1 | |
| 1543189 | 16 HARNESS AS | 1 | |
| 1543190 | 17 HARNESS AS-ENGINE | 1 | |
| 1543194 | 18 CABLE AS | 1 | |
| 1543195 | 19 CABLE AS | 1 | |
| 1543197 | 20 SWITCH GP-START | 1 | |
| 1587833 | 21 WIRE AS-SWITCH (SPEED SELECT)(TWO SPEED) | 1 | |
| 1912272 | 22 BRACKET | 1 | |
| 1687908 | 23 SWITCH GP-MAGNETIC (12-VOLT)(MAIN POWER) | 1 | |
| 1028807 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 3E3362 | WEDGE-PLUG LOCK (2-PIN) | 1 | |
| 4F2294 | NUT-JAM (5/16-24-THD) | 2 | |
| 6V8186 | NUT-FULL (5/16-24-THD) | 2 | |
| 8T8730 | SOCKET-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1754280 | 24 BATTERY (12-VOLT)(500 CCA) | 1 | |
| 1876495 | 25 HARNESS AS-PANEL | 1 | |
| 1028802 | 26 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | 27 KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028804 | 28 KIT-RECEPTACLE (4-PIN) | 1 | |
| 4P7581 | 29 CLIP | 1 | |
| 4P8134 | 30 CLIP | 1 | |
| 5C2874 | 31 NUT (M5X0.8-THD) | 6 | |
| 5C8312 | 32 NUT (M4X0.7-THD) | 2 | |
| 5C9553 | 33 BOLT (M6X1X16-MM) | 2 | |
| 5L4507 | 34 SCREW-MACHINE (10-32X0.875-IN) | 4 | |
| 6V7357 | 35 BOLT (M6X1X25-MM) | 1 | |
| 6V9672 | 36 SCREW-MACHINE (M4X0.7X16-MM) | 2 | |
| 6V9674 | 37 SCREW-MACHINE (M5X0.8X14-MM) | 6 | |
| 7X2537 | 38 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4133 | 39 NUT (M10X1.5-THD) | 1 | |
| 8T4171 | 40 BOLT (M6X1X12-MM) | 12 | |
| 8T4205 | 41 WASHER-HARD (7.2X14.5X2-MM THK) | 9 | |
| 8T4223 | 42 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 43 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4244 | 44 NUT (M12X1.75-THD) | 1 | |
| 9G3695 | 45 PLUG-SEAL | 9 | |
| 9H1958 | 46 CIRCUIT BREAKER GP (20-AMPERE) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 1712208 | 47 CIRCUIT BREAKER AS (60-AMPERE) | 2 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 1H3244 | LOCKWASHER | 2 | |
| 3S2093 | 48 STRAP-CABLE | 1 | |
| 7K1181 | 49 STRAP-CABLE | 13 | |
| 1939141 | 50 COVER-TERMINAL | 2 |
