System And Components
231-2853 BATTERY & WIRING GPS/N BFA2982-UP; BDH1030-UP; 3YW4241-UP
Group No: 231-2853
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 13 | |
| 8I4641 | 2 STRAP-GROUND | 1 | |
| 8T8737 | 3 PLUG-SEAL | 9 | |
| 0897365 | 4 WASHER (7X24X10-MM THK) | 1 | |
| 1068704 | 5 SUPPRESSOR AS-ARC (GLOW PLUG) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1092350 | 6 SWITCH AS-ROCKER (WARNING BEACON, POWER RECEP) | 1 | |
| 1117899 | GASKET | 1 | |
| 1138490 | 7 FUSE (10-AMPERE) | 8 | |
| 1138492 | 8 FUSE (20-AMPERE) | 1 | |
| 1151615 | 9 RELAY AS (12-VOLT)(GLOW PLUG) | 1 | |
| 1151615 | 9A RELAY AS (12-VOLT)(STARTER) | 1 | |
| 1151615 | 9B RELAY AS (12-VOLT)(FLOODLIGHT) | 1 | |
| 1151615 | 9C RELAY AS (12-VOLT)(MAIN) | 1 | |
| 1151615 | 9D RELAY AS (12-VOLT)(MAIN) | 1 | |
| 1200667 | 10 SENDER-TEMPERATURE (COOLANT) | 1 | |
| 1284249 | 11 LOCKWASHER | 1 | |
| 1313798 | 12 BASE | 1 | |
| 1394972 | 13 SPACER AS | 1 | |
| 1469439 | 14 RELAY AS (12-VOLT)(BOOM LOWER) | 1 | |
| 1469439 | 14A RELAY AS (12-VOLT)(START DISABLE) | 1 | |
| 1543194 | 15 CABLE AS | 1 | |
| 1S7252 | TERMINAL-CABLE (00-GA, 3/8-IN SCREW) | 1 | |
| 3S6049 | TERMINAL AS-BATTERY (POSITIVE) | 1 | |
| 5P0761 | CABLE (00-GA, RED)(70-CM) | ||
| 8N0869 | COVER-TERMINAL (RED) | 1 | |
| 8N1725 | COVER AS-TERMINAL (RED) | 1 | |
| 1543195 | 16 CABLE AS | 1 | |
| 1S7251 | TERMINAL-CABLE (00-GA, 1/2-IN SCREW) | 1 | |
| 3S6050 | TERMINAL AS-BATTERY (NEGATIVE) | 1 | |
| 5P0747 | CABLE (00-GA, BLACK)(80-CM) | ||
| 7N5274 | COVER AS-TERMINAL (BLACK) | 1 | |
| 1543197 | 17 SWITCH GP-START (KEY) | 1 | |
| 1712208 | 18 CIRCUIT BREAKER AS (60-AMPERE)(ALTERNATOR) | 1 | |
| 6V8187 | NUT (1/4-28-THD) | 2 | |
| 8T4205 | WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 2532111 | LOCKWASHER | 2 | |
| 1754280 | 19 BATTERY (12-VOLT) | 1 | |
| 1912272 | 20 BRACKET | 1 | |
| 2032311 | 21 GAUGE GP-CLUSTER | 1 | |
| 2110052 | 22 NUT (1-11/16-18-THD) | 1 | |
| 2311861 | 23 HARNESS AS-CONSOLE | 1 | |
| 9X1054 | PLUG AS-CONNECTOR (4-PIN) | 3 | |
| 1977259 | RECEPTACLE AS-CONNECTOR (19-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | KIT-RECEPTACLE (3-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552274 | KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 2311863 | 24 HARNESS AS-PLATFORM | 1 | |
| 1552272 | PLUG AS-CONNECTOR (4-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1552260 | KIT-CONNECTING PLUG (3-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 2311864 | 25 HARNESS AS-ENGINE | 1 | |
| 9X1054 | PLUG AS-CONNECTOR (4-PIN) | 3 | |
| 1761477 | PLUG AS (2-PIN) | 1 | |
| 1977261 | PLUG AS-CONNECTOR (19-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1293178 | 26 LOCKNUT (M6X1-THD) | 5 | |
| 1471380 | 27 SWITCH AS-FOOT (SPEED SELECT) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 1550013 | 28 HORN (12-VOLT) | 1 | |
| 1939141 | 29 COVER-TERMINAL | 2 | |
| 1028802 | 30 KIT-RECEPTACLE (2-PIN) | 1 | |
| 1028803 | 31 KIT-RECEPTACLE (3-PIN) | 1 | |
| 1028804 | 32 KIT-RECEPTACLE (4-PIN) | 1 | |
| 3S2093 | 33 STRAP-CABLE | 1 | |
| 4P7581 | 34 CLIP | 1 | |
| 4P8134 | 35 CLIP | 1 | |
| 5C9553 | 36 BOLT (M6X1X16-MM) | 5 | |
| 5L4507 | 37 SCREW-MACHINE (10-32X0.875-IN) | 2 | |
| 6V1322 | 38 BOLT (1/4-20X0.375-IN) | 2 | |
| 6V7357 | 39 BOLT (M6X1X25-MM) | 1 | |
| 7X2537 | 40 BOLT (M8X1.25X35-MM) | 1 | |
| 8T4133 | 41 NUT (M10X1.5-THD) | 1 | |
| 8T4171 | 42 BOLT (M6X1X12-MM) | 6 | |
| 8T4205 | 43 WASHER-HARD (7.2X14.5X2-MM THK) | 13 | |
| 8T4223 | 44 WASHER-HARD (13.5X25.5X3-MM THK) | 3 | |
| 8T4224 | 45 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 8T4244 | 46 NUT (M12X1.75-THD) | 1 | |
| 8T8799 | 47 BOOT (RED) | 1 | |
| 1973800 | 48 LOOM (6.5-CM) | ||
| 1973800 | 48A LOOM (8.5-CM) | ||
| 7X7877 | 49 STRIP-EDGE |
