System And Components
145-4250 SUPPORT GP-SEATS/N BFA1-UP; BDH1-UP; 3YW1199-UP
Group No: 145-4250
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1092356 | 1 PLUG | 3 | |
| 1471080 | 2 BOX | 1 | |
| 1508899 | 3 FILM-INSTRUCTION (CONSOLE) | 1 | |
| 1664945 | 4 SUPPORT GP-SEAT | 1 | |
| 1880181 | 5 BOX | 1 | |
| 1587781 | 6 ARMREST AS | 2 | |
| 1973818 | 7 SWITCH AS-LIMIT (START) | 2 | |
| 0L1013 | NUT (1/2-20-THD) | 2 | |
| 8T4121 | 9 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4191 | 10 BOLT (M10X1.5X16-MM) | 4 | |
| 9X2042 | 11 SCREW-TRUSS HEAD (M6X1X12-MM) | 12 |
