System And Components
151-7295 SUPPORT GP-SEATS/N 3YW1-UP
Group No: 151-7295
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1095008 | 1 BUMPER-CONICAL | 1 | |
| 1394952 | 2 SHAFT AS | 2 | |
| 1471058 | 3 PLATE AS | 1 | |
| 1471069 | 4 PLATE AS | 1 | |
| 1471076 | 5 SPRING GP-GAS | 1 | |
| 1489452 | 6 PLATE AS | 1 | |
| 1522757 | 7 CONSOLE GP-OPERATOR (LH) | 1 | |
| 1522765 | 8 CONSOLE GP-OPERATOR (RH) | 1 | |
| 1522766 | 9 BRACKET AS | 1 | |
| 1592152 | 10 ADJUSTER GP-SEAT | 1 | |
| 5C7261 | 11 NUT (M8X1.25-THD) | 2 | |
| 8T4189 | 12 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4199 | 13 BOLT (M8X1.25X12-MM) | 3 | |
| 8T4224 | 14 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 9S5282 | 15 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 9X2616 | 16 SCREW-SOCKET (M8X1.25X16-MM) | 4 | |
| 3E8299 | 17 SEAL (26CM) | ||
| 7X7877 | 18 STRIP-EDGE (70CM) | ||
| 5P4116 | 19 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 9X2042 | 20 SCREW-TRUSS HEAD (M6X1X12-MM) | 4 | |
| 1542640 | 21 COVER AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 4 |
