System And Components
Assembly
100%

151-7296 SUPPORT GP-SEATS/N 3YW1-1198

Group No: 151-7296
Part NumberPart NameQty
10950081 BUMPER-CONICAL2
13949522 SHAFT AS2
14710583 PLATE AS1
14710694 PLATE AS1
14710765 SPRING GP-GAS2
14894526 PLATE AS1
14894537 PLATE AS1
15227578 CONSOLE GP-OPERATOR (LH)1
15227589 CONSOLE GP-OPERATOR (RH)1
159215210 ADJUSTER GP-SEAT1
5C726111 NUT (M8X1.25-THD)4
8T418912 BOLT (M8X1.25X20-MM)2
8T419913 BOLT (M8X1.25X12-MM)2
8T422414 WASHER-HARD (8.8X16X2-MM THK)2
9S528215 WASHER-HARD (8.8X14.5X2-MM THK)2
9X261616 SCREW-SOCKET (M8X1.25X16-MM)4
3E829917 SEAL
7X787718 STRIP-EDGE
5P411619 WASHER-HARD (8.8X20.5X2-MM THK)2
9X204220 SCREW-TRUSS HEAD (M6X1X12-MM)8
154263921 COVER AS1
6V9632NUT-WELD (M6X1-THD)4
154264022 COVER AS1
6V9632NUT-WELD (M6X1-THD)4
