System And Components
166-4945 SUPPORT GP-SEATS/N BFA1-1179; BDH1-596; 3YW1199-2817
Group No: 166-4945
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1095008 | 1 BUMPER-CONICAL | 2 | |
| 1394952 | 2 SHAFT AS | 2 | |
| 1471076 | 3 SPRING GP-GAS | 2 | |
| 1489452 | 4 PLATE AS | 1 | |
| 1489453 | 5 PLATE AS | 1 | |
| 1522757 | 6 CONSOLE GP-OPERATOR (LH) | 1 | |
| 1522758 | 7 CONSOLE GP-OPERATOR (RH) | 1 | |
| 1542639 | 8 COVER AS | 1 | |
| 1542640 | 9 COVER AS | 1 | |
| 1592152 | 10 ADJUSTER GP-SEAT | 1 | |
| 1764068 | 11 PLATE AS | 1 | |
| 1836144 | 12 PLATE AS | 1 | |
| 5C7261 | 13 NUT (M8X1.25-THD) | 4 | |
| 5P4116 | 14 WASHER-HARD (8.8X20.5X2-MM THK) | 2 | |
| 8T4189 | 15 BOLT (M8X1.25X20-MM) | 2 | |
| 8T4199 | 16 BOLT (M8X1.25X12-MM) | 2 | |
| 8T4224 | 17 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 9S5282 | 18 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 9X2042 | 19 SCREW-TRUSS HEAD (M6X1X12-MM) | 8 | |
| 9X2616 | 20 SCREW-SOCKET (M8X1.25X16-MM) | 4 | |
| 3E8299 | 21 SEAL (26CM) | ||
| 7X7877 | 22 STRIP-EDGE (126CM) |
