System And Components
195-5841 SUPPORT GP-SEATS/N BFA1-UP; BDH1-UP; 3YW1-UP
Group No: 195-5841
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T2444 | 1 STUD-BALL | 2 | |
| 1394952 | 2 SHAFT AS | 2 | |
| 1396365 | 3 BUSHING-PLASTIC | 4 | |
| 1592152 | 4 ADJUSTER GP-SEAT | 1 | |
| 1782593 | 5 BUMPER | 1 | |
| 1836144 | 6 PLATE AS | 1 | |
| 1955838 | 7 BOX AS | 1 | |
| 1955839 | 8 BOX AS | 1 | |
| 1955840 | 9 PLATE AS | 1 | |
| 1991234 | 10 HANDLE AS | 1 | |
| 2054598 | 11 CYLINDER AS-GAS | 1 | |
| 2055596 | 12 SPACER (11X15X35-MM THK) | 1 | |
| 1293178 | 13 LOCKNUT (M6X1-THD) | 2 | |
| 5C7261 | 14 NUT (M8X1.25-THD) | 1 | |
| 5C9553 | 15 BOLT (M6X1X16-MM) | 2 | |
| 8T4200 | 16 BOLT (M8X1.25X16-MM) | 2 | |
| 8T4205 | 17 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4224 | 18 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8T6869 | 19 BOLT (M8X1.25X60-MM) | 1 | |
| 9S5282 | 20 WASHER-HARD (8.8X14.5X2-MM THK) | 2 | |
| 9X2616 | 21 SCREW-SOCKET (M8X1.25X16-MM) | 4 | |
| 3E8299 | 22 SEAL (26CM) | ||
| 7X7877 | 23 STRIP-EDGE (126CM) |
