System And Components
Assembly
100%

208-5093 SUPPORT GP-SEATS/N 4AZ1-UP

Group No: 208-5093
Part NumberPart NameQty
8T24441 STUD-BALL2
8T28942 LOCK AS-CYLINDER (SEAT)1
2260292LOCK AS1
2260321CAM1
13949523 SHAFT AS2
13963654 BUSHING-PLASTIC4
15921525 ADJUSTER GP-SEAT1
15974286 SUPPORT AS1
16258467 CONTROL GP-GOVERNOR1
16293788 FLOORPLATE AS1
7X78779 STRIP-EDGE (9.5-CM EACH)
178259310 BUMPER1
195583811 BOX AS (LH)1
195583912 BOX AS (RH)1
195584013 PLATE AS1
199123414 HANDLE AS1
205459815 CYLINDER AS-GAS1
205559616 SPACER (11X15X35-MM THK)1
208565117 COVER AS1
129317818 LOCKNUT (M6X1-THD)2
5C726119 NUT (M8X1.25-THD)1
5C955320 BOLT (M6X1X16-MM)2
7X772921 WASHER (11X25X3-MM THK)4
8T412122 WASHER-HARD (11X21X2.5-MM THK)2
8T413623 BOLT (M10X1.5X25-MM)4
8T413724 BOLT (M10X1.5X20-MM)2
8T420025 BOLT (M8X1.25X16-MM)2
8T420526 WASHER-HARD (7.2X14.5X2-MM THK)2
8T422427 WASHER-HARD (8.8X16X2-MM THK)3
8T686928 BOLT (M8X1.25X60-MM)1
9S528229 WASHER-HARD (8.8X14.5X2-MM THK)2
9X204430 SCREW-TRUSS HEAD (M6X1X16-MM)5
9X261631 SCREW-SOCKET (M8X1.25X16-MM)4
3E829932 SEAL (13-CM EACH)
3E829932A SEAL (30-CM EACH)
3E829932B SEAL (29.5-CM)
