System And Components
163-7694 SUPPORT GP-SEATS/N ANR1-UP
Group No: 163-7694
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1637695 | 1 CONSOLE GP-OPERATOR (RH) | 1 | |
| 1637696 | 2 CONSOLE GP-OPERATOR (LH) | 1 | |
| 1592152 | 3 ADJUSTER GP-SEAT | 1 | |
| 1095008 | 4 BUMPER-CONICAL | 1 | |
| 5C7261 | 5 NUT (M8X1.25-THD) | 6 | |
| 1852085 | 6 PLATE AS | 1 | |
| 5P4116 | 7 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 1722643 | 8 PLATE AS | 1 | |
| 6V9632 | NUT-WELD (M6X1-THD) | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 1 | |
| 7X7877 | 9 STRIP-EDGE (19CM) | ||
| 8T4224 | 10 WASHER-HARD (8.8X16X2-MM THK) | 13 | |
| 1637656 | 11 PLATE AS | 1 | |
| 8T3612 | NUT-WELD (M8X1.25-THD) | 9 | |
| 1471076 | 12 SPRING GP-GAS | 1 | |
| 1394952 | 13 SHAFT AS | 2 | |
| 8T4189 | 14 BOLT (M8X1.25X20-MM) | 6 | |
| 8T3425 | 15 CHANNEL-TRIM (.13M EACH) | ||
| 1542640 | 16 COVER AS | 1 | |
| 8T4908 | 17 BOLT (M8X1.25X25-MM) | 8 | |
| 9X2042 | 18 SCREW-TRUSS HEAD (M6X1X12-MM) | 5 |
