System And Components
Assembly
100%

183-1250 ENGINE ARType 1

Group No: 183-1250
Part NumberPart NameQty
15353871 PLUG4
6B09242 BALL BEARING1
15353913 PLUG1
29084554 PLATE1
21526185 GASKET1
15354146 SEAL1
15359367 WASHER4
15368308 PAN-OIL1
15368329 WASHER2
153683310 BOLT20
219466911 GASKET1
153683512 SEAL-O-RING1
153683713 STRAINER1
153683814 BOLT (M6X1X12-MM)5
153684715 ROTOR1
153684816 COVER1
153684917 SPRING1
153685018 COLLAR1
153685119 CLIP1
153685220 VALVE-RELIEF1
153685321 SEAL-O-RING1
153685422 HOSE (FUMES DISPOSAL)1
153685523 CLAMP-HOSE1
153687924 STUD-HOLLOW1
153688025 TUBE AS-OIL1
153688126 BOLT (M8X1.25X18-MM)2
160415027 SHIM (0.1-MM THK)1
1604151SHIM (0.15-MM THK)1
1604152SHIM (0.2-MM THK)1
1604153SHIM (0.5-MM THK)1
165360531 PLUG-DRAIN (DRAIN)(ENGINE OIL)2
220152332 FILTER AS-ENGINE OIL1
180611733 TUBE-OIL1
183116334 STUD1
183116435 STUD1
183125136 SHAFT AS-GEAR1
292174137 BUSHING1
153553538 ROD AS-CONNECTING3
153553638A BUSHING1
153553738B BOLT2
153553838C NUT2
197058139 PISTON AS3
153554039A PIN1
153554139B CLIP2
153554239C KIT-PISTON RING1
197057740 CRANKSHAFT GP1
153538041 CYLINDER BLOCK GP1
153538542 PLUG1
153538643 PLUG4
153539244 BEARING1
153539345 DOWEL2
153539446 DOWEL2
153539547 DOWEL2
153539648 PIN2
153539749 BOLT (M16X1.5-THD)2
153540750 STUD (M6X1X28-MM)2
153540851 BOLT2
153540952 CLIP1
153540053 CAP AS-BEARING1
153540253A DOWEL2
153540353B BOLT2
153540454 CAP AS-BEARING1
153540254A DOWEL2
153540354B BOLT2
153540555 CAP AS-BEARING1
153540255A DOWEL2
153540355B BOLT2
