System And Components
120-9913 AIR COMPRESSOR GP150 CC. INSTALLED IN TIMING GEAR HOUSING LH FRONT
Group No: 120-9913
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C1809 | 1 SPACER (8X19X6.5-MM) | 1 | |
| 5D1026 | 2 CLAMP-BAND | 4 | |
| 6I0233 | 3 NUT (M12X1.75-THD) | 3 | |
| 6I0254 | 4 BOLT (M8X1.25X30-MM) | 2 | |
| 6I0594 | 5 NUT (M10X1.5-THD) | 2 | |
| 6I4200 | 6 BOLT (M10X1.5X16-MM) | 2 | |
| 1394735 | 7 AIR COMPRESSOR GP | 1 | |
| 0357293 | 8 COVER | 1 | |
| 0358017 | 9 UNION | 1 | |
| 0676810 | 10 WASHER | 1 | |
| 1003714 | 11 STUD | 2 | |
| 1013917 | 12 WASHER (10.5X21X2-MM THK) | 2 | |
| 1134608 | 13 ADAPTER | 1 | |
| 1134616 | 14 CONNECTOR | 4 | |
| 1134626 | 15 GASKET | 1 | |
| 1243815 | 16 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 17 GEAR (28-TEETH) | 1 | |
| 1263205 | 18 BRACKET | 1 | |
| 1263206 | 19 HUB | 1 | |
| 1263207 | 20 SEAL-O-RING | 1 | |
| 1263208 | 21 BEARING | 1 | |
| 1263209 | 22 GEAR (32-TEETH) | 1 | |
| 1263210 | 23 PLATE | 1 | |
| 1263211 | 24 BOLT | 3 | |
| 1263212 | 25 BOLT (M8X1.25X25-MM) | 4 | |
| 1263213 | 26 TUBE AS | 1 | |
| 1480649 | 27 HOSE | 1 | |
| 1263215 | 28 HOSE | 1 | |
| 1263216 | 29 STUD | 1 | |
| 1263217 | 30 STUD | 1 | |
| 1263218 | 31 BRACKET | 1 | |
| 1263219 | 32 SEAL-O-RING | 1 |
