System And Components
161-2846 AIR COMPRESSOR GP250 CC COMPRESSOR WITH SAE DRIVE
Group No: 161-2846
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1395327 | 1 AIR COMPRESSOR GP | 1 | |
| 1263208 | 2 BEARING | 1 | |
| 6I0217 | 3 BOLT (M8X1.25X20-MM) | 2 | |
| 6I0646 | 4 BOLT (M10X1.5X14-MM) | 1 | |
| 6I0654 | 5 BOLT (M10X1.5X25-MM) | 2 | |
| 6I4200 | 6 BOLT (M10X1.5X16-MM) | 2 | |
| 1004830 | 7 BOLT (M10X1.5X20-MM) | 1 | |
| 1243815 | 9 BOLT (M8X1.25X16-MM) | 3 | |
| 1263211 | 10 BOLT | 3 | |
| 1263212 | 11 BOLT (M8X1.25X25-MM) | 4 | |
| 1263205 | 12 BRACKET | 1 | |
| 1283831 | 13 BRACKET | 1 | |
| 5D1026 | 14 CLAMP-BAND | 4 | |
| 1134616 | 15 CONNECTOR | 4 | |
| 1134626 | 16 GASKET | 1 | |
| 1263204 | 17 GEAR (28-TEETH) | 1 | |
| 1263209 | 18 GEAR (32-TEETH) | 1 | |
| 1263215 | 19 HOSE | 1 | |
| 1283830 | 20 HOSE | 1 | |
| 1263206 | 22 HUB | 1 | |
| 6I0233 | 23 NUT (M12X1.75-THD) | 3 | |
| 1263210 | 24 PLATE | 1 | |
| 7C2851 | 25 PLUG | 1 | |
| 1263207 | 26 SEAL-O-RING | 1 | |
| 1263219 | 27 SEAL-O-RING | 1 | |
| 6B0933 | 28 SPACER (10.31X19.05X6.35-MM THK) | 1 | |
| 1263216 | 29 STUD | 1 | |
| 1263217 | 30 STUD | 1 | |
| 1283829 | 31 TUBE AS | 1 | |
| 1030173 | 31A CLIP | 1 | |
| 0358017 | 32 UNION | 2 | |
| 0676810 | 33 WASHER | 1 | |
| 1013917 | 34 WASHER (10.5X21X2-MM THK) | 2 | |
| 0357293 | 35 COVER | 1 |
