System And Components
186-0814 AIR COMPRESSOR GPAN ATTACHMENT
Group No: 186-0814
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5D1026 | 1 CLAMP-BAND | 4 | |
| 6I0233 | 2 NUT (M12X1.75-THD) | 3 | |
| 6I0260 | 3 BOLT (M8X1.25X25-MM) | 2 | |
| 6I0594 | 4 NUT (M10X1.5-THD) | 2 | |
| 6I4200 | 5 BOLT (M10X1.5X16-MM) | 2 | |
| 0357293 | 6 COVER | 1 | |
| 0358017 | 7 UNION | 1 | |
| 0676810 | 8 WASHER | 1 | |
| 1003714 | 9 STUD | 2 | |
| 1013917 | 10 WASHER (10.5X21X2-MM THK) | 4 | |
| 1134608 | 11 ADAPTER | 1 | |
| 1134616 | 12 CONNECTOR | 3 | |
| 1134626 | 13 GASKET | 1 | |
| 1243815 | 14 BOLT (M8X1.25X16-MM) | 3 | |
| 1263204 | 15 GEAR (28-TEETH) | 1 | |
| 1263205 | 16 BRACKET | 1 | |
| 1263206 | 17 HUB | 1 | |
| 1263207 | 18 SEAL-O-RING | 1 | |
| 1263208 | 19 BEARING | 1 | |
| 1263209 | 20 GEAR (32-TEETH) | 1 | |
| 1263210 | 21 PLATE | 1 | |
| 1263211 | 22 BOLT | 3 | |
| 1263212 | 23 BOLT (M8X1.25X25-MM) | 4 | |
| 1263213 | 24 TUBE AS | 1 | |
| 1263216 | 25 STUD | 1 | |
| 1263218 | 26 BRACKET | 1 | |
| 1263219 | 27 SEAL-O-RING | 1 | |
| 1395327 | 28 AIR COMPRESSOR GP | 1 | |
| 1752237 | 29 STUD | 1 | |
| 1860707 | 30 HOSE | 1 | |
| 1860811 | 31 HOSE | 1 |
