System And Components
222-3582 AIR COMPRESSOR GPALSO AN ATTACHMENT
Group No: 222-3582
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B0858 | 1 PLUG-PIPE | 1 | |
| 6I0217 | 2 BOLT (M8X1.25X20-MM) | 1 | |
| 6I0233 | 3 NUT (M12X1.75-THD) | 3 | |
| 6I0646 | 4 BOLT (M10X1.5X14-MM) | 1 | |
| 1243815 | 5 BOLT (M8X1.25X16-MM) | 3 | |
| 1263205 | 6 BRACKET | 1 | |
| 1263206 | 7 HUB | 1 | |
| 1263207 | 8 SEAL-O-RING | 1 | |
| 1263208 | 9 BEARING | 1 | |
| 1263209 | 10 GEAR (32-TEETH) | 1 | |
| 1263210 | 11 PLATE | 1 | |
| 1263211 | 12 BOLT | 3 | |
| 1263212 | 13 BOLT (M8X1.25X25-MM) | 4 | |
| 1263216 | 14 STUD | 1 | |
| 1263217 | 15 STUD | 1 | |
| 1263219 | 16 SEAL-O-RING | 1 | |
| 1860667 | 17 COVER | 1 | |
| 2143203 | 18 WASHER (SEALING) | 1 |
