System And Components
176-1360 CYLINDER BLOCK GPS/N 5MF1-1183
Group No: 176-1360
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 0L1138 | 1 BOLT (3/8-24X0.5-IN) | 3 | |
| 1N3762 | 2 PLUG-CUP | 9 | |
| 6I0195 | 3 PLUG | 1 | |
| 6I0219 | 4 PLATE | 1 | |
| 6I0220 | 5 GASKET | 1 | |
| 6I0298 | 6 GASKET | 1 | |
| 6I0302 | 7 BOLT (M10X1.5X25-MM) | 4 | |
| 6I0572 | 8 BOLT (M8X1.25X20-MM) | 2 | |
| 6I1074 | 9 VALVE AS (OIL JET) | 4 | |
| 6I0686 | 9A SPRING | 1 | |
| 6I1075 | 9B BALL | 1 | |
| 6I1076 | 9C RETAINER | 1 | |
| 7W2501 | 10 PLUG | 1 | |
| 8F2534 | 11 GASKET | 1 | |
| 9Y5015 | 12 PLUG-FREEZE | 1 | |
| 0358068 | 13 BOLT (5/8-18X3.75-IN) | 10 | |
| 0365802 | 14 BEARING | 1 | |
| 0676002 | 15 DOWEL | 10 | |
| 0676006 | 16 PLUG | 2 | |
| 0676043 | 17 PLUG-SIDE | 6 | |
| 0676805 | 18 PLUG | 1 | |
| 0676808 | 19 PLUG | 1 | |
| 0679520 | 20 SPACER | 3 | |
| 0691124 | 21 PLUG | 2 | |
| 1013923 | 22 PLATE | 1 | |
| 1483026 | 24 JET AS-PISTON COOLING | 4 | |
| 1487549 | 24A DOWEL | 1 | |
| 1761361 | 25 PLUG | 1 |
