System And Components
234-4295 CYLINDER BLOCK GPS/N 5MF1-1183
Group No: 234-4295
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1N3762 | 1 PLUG-CUP | 6 | |
| 6I0219 | 2 PLATE | 1 | |
| 6I0220 | 3 GASKET | 1 | |
| 6I0298 | 4 GASKET | 1 | |
| 6I0302 | 5 BOLT (M10X1.5X25-MM) | 4 | |
| 8T0269 | 6 BOLT-SOCKET HEAD (M6X1X20-MM) | 2 | |
| 6I0572 | 7 BOLT (M8X1.25X20-MM) | 2 | |
| 6I1074 | 8 VALVE AS (OIL JET) | 1 | |
| 6I0686 | 8A SPRING | 1 | |
| 5B9318 | 8B BALL | 1 | |
| 6I1076 | 8C RETAINER | 1 | |
| 7W2501 | 9 PLUG | 1 | |
| 4943830 | 10 PLUG-FREEZE | 1 | |
| 0358068 | 11 BOLT (5/8-18X3.75-IN) | 10 | |
| 0365802 | 12 BEARING | 1 | |
| 0676002 | 13 DOWEL | 10 | |
| 0676006 | 14 PLUG | 3 | |
| 0676043 | 15 PLUG-SIDE | 6 | |
| 0676805 | 16 PLUG | 1 | |
| 0676808 | 17 PLUG | 1 | |
| 0691124 | 18 PLUG | 1 | |
| 1013923 | 19 PLATE | 1 | |
| 1483026 | 20 JET AS-PISTON COOLING | 1 | |
| 1619820 | 21 PIN | 2 | |
| 1761361 | 22 PLUG | 1 | |
| 2071753 | 23 PLUG | 3 | |
| 1130309 | 24 BRIDGE | 1 | |
| 2141668 | 25 WASHER-SPECIAL | 1 | |
| 2152103 | 26 PLUG | 4 |
