207-7934 TURBOCHARGER GPS/N 7BJ19000-64615

Group No: 207-7934
Part NumberPart NameQty
6I02201 GASKET1
6I02602 BOLT (M8X1.25X25-MM)2
6I05633 NUT (M10X1.5-THD)4
6I05724 BOLT (M8X1.25X20-MM)2
10037515 BOLT (M8X1.25X65-MM)2
5D10266 CLAMP-BAND2
06430587 CLAMP-HOSE2
10527408 BOLT (M8X1.25X40-MM)8
10689169 BOLT (M6X1X16-MM)1
114259010 CONNECTION1
124381511 BOLT (M8X1.25X16-MM)1
138204312 WASHER2
139700913 MANIFOLD AS-EXHAUST1
148713214 FERRULE2
143453415 HOSE1
143911216 GASKET2
146002917 HOSE1
146184118 BOLT4
148712719 ELBOW1
148712820 GASKET1
207792521 MANIFOLD-INLET1
148713522 TUBE1
101392123 CLIP1
148713624 TUBE1
148713925 CONNECTION1
149000926 TURBOCHARGER GP1
149423627 STUD (M10X1.5X37-MM)4
154804428 CLIP1
162159129 TUBE AS1
164401930 CLIP1
174963831 BOLT (M10X1.5X30-MM)8
148713832 BOLT1
194539033 GASKET-MANIFOLD1
138206534 GASKET1
6I063135 BOLT (M6X1X12-MM)2
1676920KIT-ACTUATOR MOUNTING1
1676921KIT-TURBOCHARGER1
