System And Components
195-1284 LINES GP-RIDE CONTROLS/N BML2281-4799
Group No: 195-1284
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2247830 | 1 FILM-WARNING (HIGH PRESSURE, READ OMM, U.S.) | 1 | |
| 1623960 | 2 ACCUMULATOR GP-RIDE CONTROL (CHARGED) | 1 | |
| 1625380 | 3 HOSE AS | 1 | |
| 1908315 | 4 MANIFOLD GP-RIDE CONTROL (RIDE CONTROL) | 1 | |
| 2327497 | 5 HOSE AS | 1 | |
| 2327498 | 6 HOSE AS | 1 | |
| 1951288 | 7 HOSE AS | 1 | |
| 1951289 | 8 BRACKET AS | 1 | |
| 1951736 | 9 TUBE AS | 1 | |
| 1091633 | 10 CLIP (SLOT) | 2 | |
| 1091634 | 11 CLIP (TAB) | 2 | |
| 1488316 | 12 CONNECTOR AS | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488345 | 13 CONNECTOR AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8638 | CONNECTOR | 1 | |
| 1488370 | 14 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488372 | 15 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488378 | 16 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488390 | 17 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488418 | 18 REDUCER AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8942 | REDUCER-O-RING | 1 | |
| 1488447 | 19 TEE AS-SWIVEL | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 7X0872 | TEE-SWIVEL | 1 | |
| 1504043 | 20 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 7X2549 | 21 BOLT (M12X1.75X100-MM) | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4139 | 24 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 9X6580 | 26 NUT (1-3/16-12-THD) | 1 |
