241-6760 RADIATOR GP

Group No: 241-6760
Part NumberPart NameQty
6I02171 BOLT (M8X1.25X20-MM)4
36358132 CLAMP-HOSE4
15355923 NUT (M8X1.25-THD)3
15363754 BOLT AS1
6I09175 BOLT (M6X1X25-MM)2
18061186 BOLT (M8X1.25X12-MM)13
19826647 BOLT-HEAD (M14X1.5X25-MM)16
26982438 BRACKET-MOUNTING2
23666109 MOUNT1
238026510 HOSE-RADIATOR (LOWER)1
238026611 HOSE-RADIATOR (UPPER)1
238027112 RADIATOR AS1
202661612A CAP-RADIATOR1
295587612B SHROUD1
239074313 SUPPORT (MOUNTING)1
328660714 GUARD1
239078315 GUARD1
239078516 BRACKET-MOUNTING1
6I065417 BOLT (M10X1.5X25-MM)2
335824118 GUARD-FAN (RH)1
292990919 GUARD-RADIATOR (LH)1
241675820 BRACKET-MOUNTING1
241675921 BRACKET-MOUNTING1
244325922 CLIP2
