System And Components
240-6022 LINES GP-PILOTS/N DBL1-479
Group No: 240-6022
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9521 | 1 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 2 BAND-MARKER (YELLOW, L2) | 4 | |
| 4I9523 | 3 BAND-MARKER (BLUE, L3) | 2 | |
| 4I9524 | 4 BAND-MARKER (BROWN, L4) | 4 | |
| 4I9525 | 5 BAND-MARKER (ORANGE, R1) | 2 | |
| 4I9526 | 6 BAND-MARKER (WHITE, R2) | 4 | |
| 4I9527 | 7 BAND-MARKER (GREEN, R3) | 2 | |
| 4I9528 | 8 BAND-MARKER (PURPLE, R4) | 4 | |
| 7K1181 | 9 STRAP-CABLE | 15 | |
| 8T6869 | 10 BOLT (M8X1.25X60-MM) | 2 | |
| 1335813 | 11 BAND-MARKER (GRAY, P) | 4 | |
| 1490686 | 12 ACCUMULATOR GP-HYDRAULIC (CHARGED)(CHARGED) | 1 | |
| 1642274 | 13 VALVE GP-SELECTOR (2-WAY) | 1 | |
| 1649639 | 14 CONNECTOR AS | 2 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1487925 | CONNECTOR | 1 | |
| 1919102 | 15 LEVER AS | 1 | |
| 2052152 | 16 HOSE AS | 1 | |
| 2052155 | 17 HOSE AS | 1 | |
| 2052156 | 18 HOSE AS | 1 | |
| 2056371 | 19 HOSE AS | 2 | |
| 2059124 | 20 HOSE AS | 1 | |
| 2203392 | 21 VALVE & MTG GP-SOLENOID | 1 | |
| 2247830 | 22 FILM-WARNING (HIGH PRESSURE, READ OMM, U.S.) | 1 | |
| 2402577 | 23 HOSE AS | 1 | |
| 2402578 | 24 HOSE AS | 1 | |
| 2402579 | 25 HOSE AS | 1 | |
| 2402580 | 26 HOSE AS | 2 | |
| 2402581 | 27 HOSE AS | 1 | |
| 2402587 | 28 HOSE AS | 1 | |
| 2402588 | 29 HOSE AS | 1 | |
| 2402589 | 30 HOSE AS | 1 | |
| 2402590 | 31 HOSE AS | 1 | |
| 2402591 | 32 HOSE AS | 1 | |
| 2402592 | 33 HOSE AS | 1 | |
| 2402593 | 34 HOSE AS | 1 | |
| 1018296 | 35 CLIP | 2 | |
| 1488307 | 36 ADAPTER AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 5P8874 | ADAPTER | 1 | |
| 1488316 | 37 CONNECTOR AS | 4 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8647 | CONNECTOR | 1 | |
| 1488325 | 38 CONNECTOR AS | 12 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1488351 | 39 ELBOW AS | 3 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9849 | ELBOW | 1 | |
| 1488368 | 40 ELBOW AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8627 | ELBOW | 1 | |
| 1488369 | 41 ELBOW AS | 3 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8628 | ELBOW | 1 | |
| 1488385 | 42 ELBOW AS | 3 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V9000 | ELBOW | 1 | |
| 1488434 | 43 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488435 | 44 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8781 | TEE | 1 | |
| 1488448 | 45 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9842 | TEE-SWIVEL | 1 | |
| 1505968 | 46 TEE AS | 1 | |
| 4J5477 | SEAL-O-RING | 2 | |
| 6V9835 | TEE | 1 | |
| 1536248 | 47 ADAPTER AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T6663 | ADAPTER-PORT | 1 | |
| 1951141 | 48 SPACER (7.2X18X11-MM THK) | 2 | |
| 3K0360 | 49 SEAL-O-RING | 1 | |
| 5C2890 | 50 NUT (M6X1-THD) | 2 | |
| 5P4115 | 51 WASHER-HARD (7.2X19X2-MM THK) | 2 | |
| 7X7888 | 52 BOLT (M6X1X90-MM) | 2 | |
| 8T4121 | 53 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 54 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4205 | 55 WASHER-HARD (7.2X14.5X2-MM THK) | 2 | |
| 8T4224 | 56 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8S4744 | BOLT (9/16-18X1.5-IN) | 1 | |
| 2399437 | FILM (CONTROL PATTERN) | 1 | |
| 1690599 | SWITCH AS-ROCKER (HYDRAULIC LOCKOUT) | 1 | |
| 1117899 | GASKET | 1 |
