System And Components
235-5861 LINES GP-RIDE CONTROLS/N BML4800-UP
Group No: 235-5861
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3S2093 | 1 STRAP-CABLE | 1 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 1623960 | 3 ACCUMULATOR GP-RIDE CONTROL (CHARGED) | 1 | |
| 1944334 | 4 HOSE AS | 1 | |
| 1951289 | 5 BRACKET AS | 1 | |
| 1951736 | 6 TUBE AS | 1 | |
| 2432266 | 7 VALVE & MTG GP-SOLENOID (RIDE CONTROL) | 1 | |
| 2247830 | 8 FILM-WARNING (HIGH PRESSURE, READ OMM, U.S.) | 1 | |
| 2317660 | 9 HARNESS AS-RIDE CONTROL | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 2370632 | 10 HOSE AS | 1 | |
| 2451728 | 11 HOSE AS | 1 | |
| 1091633 | 12 CLIP (SLOT) | 2 | |
| 1091634 | 13 CLIP (TAB) | 2 | |
| 1488346 | 14 ELBOW AS | 1 | |
| 8T1686 | ADAPTER-ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488364 | 15 ELBOW AS | 1 | |
| 6V8625 | ELBOW | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1488370 | 16 ELBOW AS | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9851 | ELBOW | 1 | |
| 1488390 | 17 ELBOW AS | 2 | |
| 6V8626 | ELBOW | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1504043 | 18 CONNECTOR AS | 1 | |
| 6V9873 | CONNECTOR | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 5C7261 | 19 NUT (M8X1.25-THD) | 2 | |
| 8T3647 | 20 BOLT (M8X1.25X80-MM) | 2 | |
| 6V8398 | 21 SEAL-O-RING | 2 | |
| 8T4121 | 22 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4137 | 23 BOLT (M10X1.5X20-MM) | 3 | |
| 8T4139 | 24 BOLT (M12X1.75X30-MM) | 2 | |
| 8T4223 | 25 WASHER-HARD (13.5X25.5X3-MM THK) | 2 | |
| 8T4224 | 26 WASHER-HARD (8.8X16X2-MM THK) | 4 |
