System And Components
290-2483 MOUNTING GP-WIRINGS/N L1K1-UP; S1M1-UP
Group No: 290-2483
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2901229 | 1 SUPPORT | 1 | |
| 2901231 | 2 BRACKET | 1 | |
| 2901232 | 3 BRACKET | 1 | |
| 6I0235 | 4 BOLT (M12X1.75X50-MM) | 1 | |
| 6I1090 | 5 BOLT (M8X1.25X40-MM) | 2 | |
| 2704176 | 6 BRACKET-SUPPORT | 1 | |
| 2106899 | 7 BRACKET | 1 | |
| 2106900 | 8 BOLT-FLANGE HEAD (M12X1.75X100-MM) | 1 | |
| 1243815 | 9 BOLT (M8X1.25X16-MM) | 2 | |
| 1004830 | 10 BOLT (M10X1.5X20-MM) | 1 | |
| 6I0291 | 11 NUT (M8X1.25-THD) | 4 | |
| 2456541 | 12 BOLT (M5X0.8X12-MM) | 3 | |
| 1991187 | 13 NUT (M5X0.8-THD) | 3 | |
| 6I0217 | 14 BOLT (M8X1.25X20-MM) | 2 |
