System And Components
293-6298 WIRING GP-ENGINES/N L1K1-UP; S1M1-UP
Group No: 293-6298
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4319532 | 1 HARNESS AS-ENGINE | 1 | |
| 7N0718 | 2 SWITCH GP-DISCONNECT | 1 | |
| 2741232 | 3 HARNESS AS-WIRING | 1 | |
| 2741231 | 4 HARNESS AS-WIRING | 1 | |
| 2741230 | 5 BRACKET | 1 | |
| 1443852 | 6 FILM-INFORMATION (BATTERY POWER DISCONNECT) | 1 | |
| 6I0631 | 7 BOLT (M6X1X12-MM) | 6 | |
| 2937210 | 8 BRACKET | 1 | |
| 1967715 | 9 CLIP | 1 | |
| 2741237 | 10 FUSE (5-AMPERE) | 1 | |
| 6I0654 | 11 BOLT (M10X1.5X25-MM) | 2 | |
| 6I0594 | 12 NUT (M10X1.5-THD) | 2 | |
| 2434628 | 13 RELAY (24-VOLT)(START) | 2 | |
| 2434632 | 14 RELAY-GLOW PLUG (24-VOLT) | 3 | |
| 2741239 | 15 CIRCUIT BREAKER (10-AMPERE) | 1 | |
| 2741240 | 16 CIRCUIT BREAKER (80-AMPERE) | 1 | |
| 1960346 | 17 WASHER (19X10X1.9-MM THK) | 1 | |
| 1004458 | 18 BOLT (M8X1.25X14-MM) | 1 | |
| 1954615 | 19 STRAP | 4 | |
| 1960384 | 20 TIE-CABLE | 1 | |
| 8Q2778 | 21 TIE-CABLE | 1 | |
| 2741228 | 22 BRACKET | 1 | |
| 6I4200 | 23 BOLT (M10X1.5X16-MM) | 1 | |
| 1692876 | 24 FILM-IDENTIFICATION (POWER RECEPTACLE, 12-VOLT) | 1 | |
| 2720506 | 25 CONVERTER AS | 1 | |
| 1967708 | 26 LOCKNUT (M5X0.8-THD) | 3 | |
| 1967728 | 27 WASHER (5.1X11X1.3-MM THK) | 3 | |
| 1935189 | 28 SCREW (M5X0.8X12-MM) | 3 | |
| 2638001 | 29 CLIP | 1 | |
| 2637999 | 30 CLIP | 1 | |
| 2456541 | 31 BOLT (M5X0.8X12-MM) | 1 |
