System And Components
239-1103 RADIATOR GP
Group No: 239-1103
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6I0217 | 1 BOLT (M8X1.25X20-MM) | 4 | |
| 3635813 | 2 CLAMP-HOSE | 4 | |
| 1535592 | 3 NUT (M8X1.25-THD) | 3 | |
| 1536375 | 4 BOLT AS | 1 | |
| 6I0917 | 5 BOLT (M6X1X25-MM) | 2 | |
| 1806118 | 6 BOLT (M8X1.25X12-MM) | 13 | |
| 1982664 | 7 BOLT-HEAD (M14X1.5X25-MM) | 16 | |
| 2366610 | 9 MOUNT | 1 | |
| 2380265 | 10 HOSE-RADIATOR (LOWER) | 1 | |
| 2380266 | 11 HOSE-RADIATOR (UPPER) | 1 | |
| 2380271 | 12 RADIATOR AS | 1 | |
| 2026616 | 12A CAP-RADIATOR | 1 | |
| 2955876 | 12B SHROUD | 1 | |
| 4388534 | 13 BRACKET AS | 1 | |
| 3286607 | 14 GUARD | 1 | |
| 2390745 | 15 BRACKET-MOUNTING (RADIATOR, RH) | 1 | |
| 2390746 | 16 BRACKET-MOUNTING (RADIATOR, LH) | 1 | |
| 3554970 | 17 GUARD-FAN | 1 | |
| 2929909 | 18 GUARD-RADIATOR (LH)(LH) | 1 | |
| 2698240 | 19 GUARD | 1 | |
| 2698242 | 20 SUPPORT | 1 | |
| 6I0654 | 21 BOLT (M10X1.5X25-MM) | 2 | |
| 2712877 | 22 BRACKET-MOUNTING | 2 | |
| 2443259 | 23 CLIP | 2 |
