System And Components
272-1402 AIR CLEANER & RADIATOR GPS/N NCA1-UP; E1M1-UP
Group No: 272-1402
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2380265 | 1 HOSE-RADIATOR (UPPER) | 1 | |
| 2380266 | 2 HOSE-RADIATOR (LOWER) | 1 | |
| 0643058 | 3 CLAMP-HOSE | 4 | |
| 6I0217 | 4 BOLT (M8X1.25X20-MM) | 6 | |
| 6I0254 | 5 BOLT (M8X1.25X30-MM) | 2 | |
| 9M7959 | 6 CLAMP-HOSE | 2 | |
| 1036714 | 7 CLIP | 2 | |
| 1535592 | 8 NUT (M8X1.25-THD) | 3 | |
| 1536375 | 9 BOLT (M8X1.25X16-MM) | 1 | |
| 6I0917 | 10 BOLT (M6X1X25-MM) | 2 | |
| 1806118 | 11 BOLT (M8X1.25X12-MM) | 9 | |
| 2921992 | 12 SPACER | 1 | |
| 1982664 | 13 BOLT-HEAD (M14X1.5X25-MM) | 8 | |
| 2366610 | 14 MOUNT | 1 | |
| 2380271 | 15 RADIATOR AS | 1 | |
| 2026616 | 15A CAP-RADIATOR | 1 | |
| 2955876 | 15B SHROUD | 1 | |
| 2390743 | 16 SUPPORT | 1 | |
| 2698240 | 17 GUARD | 1 | |
| 2698242 | 18 SUPPORT | 1 | |
| 2391137 | 19 BOLT (M10X1.25X25-MM) | 2 | |
| 2416747 | 20 HOSE | 1 | |
| 3358241 | 21 GUARD-FAN | 1 | |
| 2929909 | 22 GUARD-RADIATOR (RH) | 1 | |
| 2416758 | 23 BRACKET-MOUNTING | 1 | |
| 2416759 | 24 BRACKET-MOUNTING | 1 | |
| 2440514 | 25 FILTER ELEMENT AS-AIR | 1 | |
| 2443259 | 26 CLIP | 2 | |
| 2471377 | 27 BRACKET-FILTER | 1 |
